神钢零件查询(BREAKER) - NIBBLER/BREAKER ATTACHMENT - SK70SR-1E/SK70SR-1ES ASN YT04-07001 (9/04-) (02-014[02]) - ARM, 1.65M (NIBBLER & BREAKER) Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
312 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YT12B00091F2 | [1] | ARM, 1. 65M (NIBBLER & BREAKER) | |
| . . | YT12B00091F3 | [1] | ARM, 1.65M (EXTRA + NIBBLER & BREAKER) | |
| 2. | YT12B01010P2 | [2] | BUSHING | KOB |
| 3. | LE12B01054P1 | [2] | BUSHING | KOB |
| 4. | YT12B01118P1 | [2] | BUSHING | KOB |
| 5. | NSS | [1] | NOT SOLD SEPARAT | CONARM, F2 ONLY |
| 5-2. | YT12B01123P1 | [1] | PLATE | |
| 5-3. | YT12B01124P1 | [1] | PLATE | |
| 5-4. | YT12B01110P1 | [1] | PLATE | KOB |
| 5-5. | 2416T24666 | [2] | BRACKET | KOB |
| 5-6. | YT12B01095P1 | [1] | BLOCK | KOB |
| 6. | NSS | [1] | NOT SOLD SEPARAT | CONARM, F3 ONLY |
| 6-2. | YT12B01123P1 | [1] | PLATE | |
| 6-3. | YT12B01124P1 | [1] | PLATE | |
| 6-4. | YT12B01110P1 | [1] | PLATE | KOB |
| 6-5. | 2416T24666 | [2] | BRACKET | KOB |
| 6-6. | YT12B01095P1 | [1] | BLOCK | KOB |
| 6-7. | 2416T10838D3 | [1] | BLOCK | KOB |
