神钢零件查询(BREAKER) - NIBBLER/BREAKER ATTACHMENT - SK70SR-1E/SK70SR-1ES ASN YT04-07001 (9/04-) (02-024) - HYD LINES, ARM 1.65M (EXTRA + NIBBLER & BREAKER) Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
355 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YT43H00051F1 | [1] | HYD LINES, ARM 1.65M | |
| 1. | YT43H01056P1 | [2] | TUBE | KOB |
| 2. | YT43H01057P1 | [1] | TUBE | KOB |
| 3. | YT43H01058P1 | [1] | TUBE | KOB |
| 4. | YT43H01069P1 | [1] | TUBE | KOBTUBE |
| 5. | YT43H01070P1 | [1] | TUBE | |
| 6. | YT43H01013DD | [2] | HOSE | KOB1050mm Long (41-21/64 in) |
| 7. | ZX58N08090 | [2] | HOSE | KOB900mm Long (35-7/16 in) |
| 8. | 24100P1006F1 | [2] | VALVE | KOBASSY Superseded by part number: 24100P1006F2 |
| 8-1. | 2436P230 | [1] | VALVE BODY | KOB |
| 8-2. | 2436T304 | [1] | VALVE | KOB |
| 8-3. | 2418T8945D1 | [1] | SPACER | KOBID 40 x OD 60 x Th 3.2mm |
| 8-4. | ZR16X04000 | [1] | RING | KOBRetaining -- ID 37 x OD 40 x Th 1.8mm |
| 8-5. | ZS23C06010 | [1] | SCREW,Hex Socket Head, M6 x 10mm | KOBM06x1.0x10mm |
| 8-6. | ZD11G04000 | [2] | O-RING,39.40mm ID x 45.60mm OD x 3.10mm | KOBID 39.40 ± 0.37 x OD 45mm |
| 8-7. | ZD12G04000 | [1] | O-RING,39.40mm ID x 45.60mm OD x 3.10mm | KOBID 39.40 ± 0.37 x OD 45mm |
| 8-8. | ZD75G04000 | [1] | BACK-UP RING | KOBID 40 x OD 45 x Th 1.25mm |
| 8-9. | ZD12G03500 | [1] | O-RING,34.40mm ID x 40.60mm OD x 3.10mm | KOBID 34.40 ± 0.33 x OD 40mm |
| 8-10. | ZD85G03500 | [1] | RING | KOBBack-Up -- ID 35 x OD 40 x Th 1.25mm |
| 8-11. | ZE82T04000 | [1] | PLUG | KOB1/4" PT |
| 9. | ZA23F22012 | [9] | HYD CONNECTOR | KOB3/4"PF - M30x1.50 x 46mm Long |
| 10. | ZA53B15000 | [2] | TEE | KOB |
| 11. | ZA82P15000 | [2] | PLUG | KOB |
| 12. | ZA83P15000 | [2] | PLUG | KOB |
| 13. | ZA93N15000 | [2] | TUBE NUT | KOB |
| 14. | ZD12P02400 | [2] | O-RING | KOBID 23.70 ± 0.24 x OD 30mm |
| 15. | ZC36X15009 | [1] | CLAMP | KOB |
| 16. | LF42H01008P1 | [2] | CLAMP | KOB |
| 17. | ZS18C08025 | [8] | SCREW,Hex, M8 x 25mm | KOBM08x1.25x25mm |
| 18. | ZS18C08040 | [1] | SCREW,Hex, M8 x 40mm | KOBM08x1.25x40mm |
| 19. | ZS18C10045 | [2] | SCREW,Hex, M10 x 45mm | KOBM10x1.50x45mm |
| 20. | ZW26X08000 | [9] | LOCK WASHER | KOBLock -- ID 08 x OD 15 x Th 2.0mm Superseded by part number: 83990583 |
| 21. | ZW26X10000 | [2] | LOCK WASHER | KOBID 10 x OD 18 x Th 2.5mm |
