神钢零件查询(CLAMSHELL) - ATTACHMENT - SK200 EXCAVATORS (1/91-12/97) (277-61) - ARM ACCESSORIES, 2.94M 24100N6511F1 Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
159 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 2416N2747 | [1] | BRACKET | |
| 2. | 2418P23233D1 | [1] | TUBE | |
| 3. | 2418P23233D2 | [1] | TUBE | |
| 4. | 2416P7129D2 | [1] | BLOCK | |
| 5. | 2419P7129D1 | [1] | BLOCK | |
| 6. | 2444Z2088F1 | [2] | JOINT, SWIVEL | |
| 6-1. | ZD12P03200 | [2] | O-RING | KOBID 31.70 ± 0.31 x OD 38mm |
| 6-2. | 2444R856 | [1] | JOINT | |
| 6-3. | 2444R857 | [1] | BODY | |
| 6-4. | 2445R364 | [2] | OIL SEAL | KOB |
| 6-5. | 2418T10005 | [1] | SPACER | KOB |
| 6-6. | 2419T3378 | [1] | PIN | |
| 7. | 2444R1091D1 | [2] | HOSE | |
| 8. | ZF23E28012 | [2] | CONNECTOR | |
| 9. | 2416T9851 | [1] | PLATE | |
| 10. | 2416T9850 | [1] | BLOCK, TAPPED | |
| 11. | 2416T10748 | [4] | BLOCK, TAPPED | |
| 12. | ZC26X28014 | [4] | CLAMP | KOBSingle Line -- 75x37x38mm (Ø28mm) |
| 13. | ZS13C14035 | [3] | CAPSCREW | KOBSCREW M14x2.0x35mm Superseded by part number: ZS18C14035 |
| 14. | ZS13C12055 | [4] | SCREW | KOBM12x1.75x55mm Superseded by part number: ZS18C12055 |
| 15. | ZS13C10025 | [4] | CAPSCREW | KOBSCREW M10x1.50x25mm Superseded by part number: ZS18C10025 |
| 16. | ZW22X14000 | [3] | LOCK WASHER | KOBID 14 x OD 24.5 x Th 3.5mm Superseded by part number: ZW26X14000 |
| 17. | ZW22X12000 | [4] | LOCK WASHER | KOBID 12 x OD 21.5 x Th 3.0mm Superseded by part number: ZW26X12000 |
| 18. | ZW22X10000 | [4] | LOCK WASHER | KOBID 10 x OD 18.4 x Th 2.5mm Superseded by part number: ZW26X10000 |
| 19. | 2419T3521 | [1] | PIN | |
| 20. | ZW16P42000 | [1] | WASHER | KOBID 43 x OD 78 x Th 7.0mm |
| 21. | ZN21C42046 | [1] | NUT | KOBM42x4.50mm Superseded by part number: ZN23C42046 |
| 22. | ZP15D08080 | [1] | COTTER PIN | KOBPin, Cotter Superseded by part number: ZP15D08100 |
| 23. | ZA82P28000 | [2] | PLUG | KOBNUT |
| 24. | ZD12P02240 | [2] | O-RING | KOBID 22.10 ± 0.24 x OD 28.4mm |
