神钢零件查询(CLAMSHELL) - ATTACHMENT - SK200 EXCAVATORS (1/91-12/97) (344-61) - JOINT ASSY, SWIVEL 24100J4829F1 Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
725 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 2408N456 | [1] | JOINT, SWIVEL | |
| 2. | 2408N458 | [1] | JOINT | |
| 3. | 2405P448 | [1] | BUSHING | |
| 4. | 2425T379 | [1] | BALL | |
| 5. | 2445Z1084 | [3] | O-RING | |
| 6. | 2405T978 | [1] | BUSHING | |
| 7. | 2405T977 | [1] | BUSHING | |
| 8. | 2418T10233 | [1] | WASHER | |
| 9. | 2420P1500 | [1] | NUT, LOCK | |
| 10. | 2419T3423 | [1] | PIN | |
| 11. | 2418P8470 | [1] | RING, STOP | |
| 12. | 2405T954 | [2] | BUSHING | |
| 13. | ZW22X16000 | [1] | WASHER, LOCK | KOBID 16 x OD 28.0 x Th 4.0mm |
| 14. | 2420T4364 | [1] | CAPSCREW | |
| 15. | ZG91S02000 | [2] | LUBE NIPPLE,1/8" NPT x 1/8" NPT | KOB1/8" PT -- Straight |
| 16. | 2420T4360 | [1] | KEY | |
| 17. | 2419T3424 | [1] | PIN | |
| 18. | 2444Z2119 | [2] | CONNECTOR | |
| 19. | 2445Z1085 | [2] | O-RING | |
| 20. | ZS13C20070 | [10] | SCREW | KOBM20x2.50x70mm |
| 21. | ZN12C20016 | [10] | NUT | KOBM20x2.50mm |
| 22. | ZN12C20012 | [10] | NUT | NUT |
| 23. | ZW11X20000 | [10] | WASHER | KOB |
| 25. | ZF33B28000 | [4] | 90 ELBOW | KOB |
| 26. | 2418T10232 | [2] | TUBE | |
| 27. | 24100T283F1 | [2] | JOINT, SWIVEL | |
| 27-1. | 2436P237 | [1] | BODY, VALVE | |
| 27-2. | 2436T312 | [1] | VALVE | |
| 27-3. | 2445Z1082 | [2] | O-RING | O-RING |
| 28. | 2418T10231 | [2] | TUBE | |
| 29. | 2444T2167 | [2] | CONNECTOR | |
| 30. | 2445Z1073 | [6] | O-RING | |
| 31. | 2416T10734 | [1] | SUPPORT | |
| 32. | ZS13C10050 | [1] | SCREW | KOBM10x1.50x50mm Superseded by part number: ZS18C10050 |
| 33. | ZN12C10008 | [1] | NUT | KOBM10x1.50mm Superseded by part number: ZN18C10008 |
| 34. | ZW22X10000 | [1] | LOCK WASHER | KOBID 10 x OD 18.4 x Th 2.5mm Superseded by part number: ZW26X10000 |
| 35. | 2420T4359 | [4] | PLUG | |
| 37. | 2432T1735 | [1] | CLAMP | |
| 38. | 2410N508 | [1] | JOINT, SWIVEL (O.P.T) USE ITEM OF 1 OR 38 | |
| 39. | ZN21C42046 | [1] | NUT | KOBM42x4.50mm Superseded by part number: ZN23C42046 |
| 40. | ZP15D08080 | [1] | COTTER PIN | KOBPin, Cotter Superseded by part number: ZP15D08100 |
| 41. | ZF93N28000 | [2] | TUBE NUT | KOB Superseded by part number: ZA93N28000 |
| 42. | ZF93S28000 | [2] | FERRULE | KOB Superseded by part number: ZA93S28000 |
| 43. | ZF83H28000 | [2] | PLUG | KOB Superseded by part number: ZA82P28000 |
| 44. | ZF83P28000 | [2] | PLUG | KOB Superseded by part number: ZA83P28000 |
