神钢零件查询(CLAMSHELL) - ATTACHMENT - SK200 EXCAVATORS (1/91-12/97) (421-61) - BUCKET ASSY, CLAMSHELL 0.5M{3} 24100J4844F3 Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
256 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 3. | 2412J539F1 | [2] | ARM | |
| 3-14. | 2405T972 | [2] | BUSHING | |
| 5. | 2416J768F1 | [1] | SUPPORT | |
| 5-12. | 2418P8484 | [1] | WASHER | |
| 5-14. | 2420T4368 | [1] | NUT, LOCK | |
| 5-15. | 2420Z958 | [1] | SETSCREW | |
| 5-16. | 2405P449 | [1] | BUSHING | |
| 7. | 2414T1931 | [1] | COVER | |
| 8. | 2414N1823 | [1] | COVER | |
| 9. | 24100P1027F1 | [2] | JOINT ASSY, SWIVEL | |
| 9-1. | 2444P768 | [1] | BODY | |
| 9-2. | 2444T2169 | [1] | UNIVERSAL JOINT | KOB |
| 9-3. | 2444T2168 | [1] | CONNECTOR | |
| 9-4. | 2414T1930 | [1] | COVER | |
| 9-5. | 2420T4365 | [1] | NUT, LOCK | |
| 9-6. | 2418T10291 | [2] | PACKING | |
| 9-7. | 2445R364 | [1] | OIL SEAL | KOB |
| 9-8. | ZF93N28000 | [1] | TUBE NUT | KOB Superseded by part number: ZA93N28000 |
| 9-9. | ZF93S28000 | [1] | FERRULE | KOB Superseded by part number: ZA93S28000 |
| 9-10. | 2445Z1083 | [1] | O-RING | |
| 9-11. | 2425Z502 | [1] | BEARING | |
| 10. | 2419T3531 | [1] | PIN | |
| 11. | 2412N308 | [5] | ADAPTER, TOOTH | |
| 12. | 2412P391 | [5] | POINT | |
| 13. | B12P0015E2 | [5] | PIN | KOB Superseded by part number: 2412Z162K |
| 14. | B12P0015E3 | [5] | LOCK PIN | KOB Superseded by part number: B12P0015E3MK |
| 15. | 2419T3443 | [4] | PIN | |
| 16. | 2419T3418 | [4] | PIN | |
| 17. | 2419T3441 | [2] | PIN | |
| 18. | 2419T3442 | [2] | PIN | |
| 19. | ZP15D06056 | [2] | SPLIT PIN/SAFETY PIN | KOB Superseded by part number: ZP15D06070 |
| 20. | ZP15D08063 | [4] | BASE PLATE Pin, Cotter | BASE PLATE Pin, Cotter |
| 21. | 2419T3384 | [6] | PIN | PIN |
| 22. | 2420Z956 | [10] | SCREW, FLAT HEAD | |
| 23. | 2420Z955 | [5] | SCREW, FLAT HEAD | |
| 24. | ZN12C24019 | [15] | NUT M24x3.0mm | NUT M24x3.0mm |
| 25. | ZW22X24000 | [15] | WASHER | KOB |
| 26. | ZW16X24000 | [2] | WASHER | WASHER |
| 27. | 2418T10283 | [4] | SPACER | |
| 28. | 2420T4340 | [2] | BOLT | |
| 29. | ZW22X14000 | [2] | LOCK WASHER | KOBID 14 x OD 24.5 x Th 3.5mm Superseded by part number: ZW26X14000 |
| 30. | 2420T4370 | [1] | BOLT | |
| 31. | ZW22X10000 | [1] | LOCK WASHER | KOBID 10 x OD 18.4 x Th 2.5mm Superseded by part number: ZW26X10000 |
| 32. | ZG91S02000 | [12] | LUBE NIPPLE,1/8" NPT x 1/8" NPT | KOB1/8" PT -- Straight |
| 33. | ZF83H28000 | [2] | PLUG | KOB Superseded by part number: ZA82P28000 |
| 34. | 2420T4369 | [2] | PLUG | |
| 36. | 2412J840F1 | [1] | BUCKET | |
| 36-20. | 2405T959 | [2] | BUSHING | |
| 37. | 2412J839F1 | [1] | BUCKET | |
| 37-20. | 2405T959 | [2] | BUSHING | |
| 38. | 2412J841 | [1] | HOLDER | |
| 39. | 2438U1011F1 | [1] | CYLINDER | |
