神钢零件查询(CLAMSHELL) - ATTACHMENT - SK200 EXCAVATORS (1/91-12/97) (426-61) - BUCKET ASSY, CLAMSHELL 0.4M{3} 24100J6397F2 Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
852 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 2412J726 | [1] | BUCKET (3 TOOTH) | |
| 2. | 2412J725 | [1] | BUCKET (2 TOOTH) | |
| 3. | 2416N3300 | [2] | EJECTOR | |
| 4. | 2412J727F1 | [2] | ARM ASSY | |
| 4-15. | 2405T972 | [2] | BUSHING | |
| 5. | 2416J768F1 | [1] | SUPPORT | |
| 5-12. | 2418P8484 | [1] | WASHER | |
| 5-14. | 2420T4368 | [1] | NUT, LOCK | |
| 5-15. | 2420Z958 | [1] | SETSCREW | |
| 5-16. | 2405P449 | [1] | BUSHING | |
| 6. | 2412J545F1 | [1] | HOLDER | |
| 6-11. | 2405T972 | [4] | BUSHING | |
| 7. | 2414T1931 | [1] | COVER | |
| 9. | 2438U719F2 | [1] | CYLINDER ASSY | CYLINDER ASSY |
| 12. | 2419T4694 | [8] | PIN | |
| 13. | 2419T3441 | [2] | PIN | |
| 14. | 2419T3442 | [2] | PIN | |
| 15. | 2419T3531 | [1] | PIN | |
| 16. | 2412N303 | [5] | TOOTH | |
| 17. | ZS13C14060 | [5] | SCREW | KOBM14x2.0x60mm Superseded by part number: ZS18C14060 |
| 18. | 2420T4370 | [1] | CAPSCREW | |
| 19. | 2420T4340 | [2] | CAPSCREW | |
| 20. | ZN31C14013 | [5] | NUT | NUT |
| 21. | ZW16P14000 | [5] | WASHER | KOBID 15 x OD 24 x Th 2.5mm |
| 22. | ZW22X14000 | [2] | LOCK WASHER | KOBID 14 x OD 24.5 x Th 3.5mm Superseded by part number: ZW26X14000 |
| 23. | ZW22X10000 | [1] | LOCK WASHER | KOBID 10 x OD 18.4 x Th 2.5mm Superseded by part number: ZW26X10000 |
| 24. | ZW16X24000 | [18] | WASHER WASHER | WASHER WASHER |
| 25. | ZP15D06056 | [10] | SPLIT PIN/SAFETY PIN | KOB Superseded by part number: ZP15D06070 |
| 26. | 2419T3384 | [2] | PIN | PIN |
| 27. | ZG91S02000 | [11] | LUBE NIPPLE,1/8" NPT x 1/8" NPT | KOB1/8" PT -- Straight |
| 29. | 2420T4369 | [2] | PLUG | |
| 30. | ZS13C20070 | [8] | SCREW | KOBM20x2.50x70mm |
| 31. | ZW11X20000 | [8] | WASHER | KOB |
| 32. | ZN12C20016 | [8] | NUT | KOBM20x2.50mm |
| 33. | ZN12C20012 | [8] | NUT | NUT |
| . . | 24100J6397F4 | [1] | BUCKET ASSY, CLAMSHELL | |
