沃尔沃零件查询TAMD60CCooling SystemOil Cooler with Installation ComponentsEPC Volvo Penta Parts catalog
广数供应链运营团队, 15 02月, 2025，浏览：
390 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
842491
|
[1] |
Oil cooler
|
|
| 2. |
820515
|
[1] |
Housing
|
|
| 3. |
821089
|
[1] |
Insert
|
|
| 4. |
842490
|
[2] |
End cover
|
|
| 5. |
838928
|
[2] |
Plug
|
|
| 6. |
838929
|
[1] |
Anode
|
|
| 7. |
914390
|
[1] |
Plug
|
|
| 8. |
907133
|
[1] |
Gasket
|
|
| 9. |
806153
|
[1] |
Gasket
|
|
| 10. |
806154
|
[2] |
Sealing ring
|
|
| 11. |
955513
|
[6] |
Hexagon screw
|
|
| 12. |
955514
|
[6] |
Hexagon screw
|
|
| 13. |
941906
|
[12] |
Spring washer
|
|
| 14. |
820516
|
[1] |
Bracket
|
See group 2A
|
| 15. |
955987
|
[1] |
O-ring
|
See group 2A
|
| 16. |
956571
|
[3] |
Hex. socket screw
|
See group 2A L=32mm
|
| 17. |
956572
|
[1] |
Hex. socket screw
|
See group 2A L=38mm
|
| 18. |
11992
|
[4] |
Gasket
|
See group 2A
|
| 19. |
842708
|
[1] |
Stay
|
|
