| . . | YY06H00007F2 | [1] | CONTROL LINES,PUMP | |
| 1. | YN50V00007F1 | [1] | VALVE | KOBFILTER ASSY, INLINE |
| 2. | ZH22X06000 | [3] | HYD CONNECTOR | KOB(Incls. O-Ring ZD12P01400) |
| 3. | ZH52X04000 | [1] | TEE,30 Degree Fl, Male, PF 1/4" x 1/4" x 1/4", O-Ring | KOB1/4" PF (Incls. O-Ring 237-6004) |
| 4. | ZH32X06000 | [2] | 90 ELBOW,Male, 30 Degree Fl, PF 3/8" x PF 3/8", O-Ring | KOBElbow, 90° -- (Incls. O-Ring ZD12P01400) Alternate O-Ring 237-6006 |
| 5. | ZH32X12000 | [1] | 90 ELBOW,Male, 30 Degree Fl, PF 3/4" x PF 3/4", O-Ring | KOBElbow, 90° -- 3/4 PF (Incls. O-Ring 237-6012) |
| 6. | ZH42X12000 | [1] | 45 ELBOW,Male, 30 Degree Fl, PF 3/4" x PF 3/4", O-Ring | KOB45° -- 3/4" PF (Incls. O-Ring 237-6012) |
| 8. | HH35X04004G3 | [1] | 90 ELBOW | KOB90° -- 1/4" PF (Incls. O-Ring ZD12P01100) |
| 9. | 2444T2505 | [1] | HYD CONNECTOR | KOB1/4" PF - 3/8" PF x 35mm Long (Incls. O-Ring ZD12P01400) |
| 10. | 2420R349D040 | [1] | HOSE,6.35mm ID x 400mm L | KOB1/4" PF, 400mm Long (15-3/4 in) |
| 11. | 2420R537D110 | [1] | HOSE ASSY.,9.60mm ID x 1100mm L | KOB Superseded by part number: HX21E06110DX |
| 12. | 2420R349D090 | [1] | HOSE,6.35mm ID x 900mm L | KOB900mm Long (35-7/16 in) |
| 13. | ZX32M12048 | [1] | HOSE | KOB |
| 14. | HH55Q06006G1 | [2] | TEE | KOB3/8" PF (Incls. O-Ring ZD12P01400) |
| 15. | ZS18C10020 | [3] | SCREW,Hex, M10 x 20mm | KOBM10x1.50x20mm |
| 16. | ZW16X10000 | [5] | WASHER | KOBID 10 x OD 21 x Th 2.0mm |
| 17. | HH25R04004G5 | [1] | HYD CONNECTOR | KOB(Incls. O-Ring ZD12P01100) |
| 18. | YY06H01002P1 | [2] | PLUG | KOB(Incls. O-Ring ZD12P01100) |
| 19. | ZH32X04006 | [1] | 90 ELBOW,Male, 30 Degree Fl, PF 1/4" x PF 3/8", O-Ring | KOB90° -- 1/4"x3/8"PF (Incls. O-Ring 237-6006 Alternate ZD12P01400) |
| 20. | ZH42X06000 | [1] | 45 ELBOW,Male, 30 Degree Fl, PF 3/8" x PF 3/8", O-Ring | KOB45° -- (Incls. O-Ring 237-6006) |
| 21. | 2444R1119D070 | [1] | HOSE | KOB700mm Long (27-1/2 in) |
| 22. | 2414Z199D60 | [1] | PROTECTIVE SLEEVE | KOB |
| 24. | PU13E01002DE | [1] | TUBE | KOB |
| 25. | ZC48X24014 | [1] | CLIP | KOBClamp, Double -- Ø24x85mm Long |
| 26. | ZE72X04000 | [1] | PLUG | KOB(PF 1/4) (Incls. O-Ring ZD12P01100) |
| 28. | YX06H01004D1 | [1] | TUBE | KOB1000mm Long (39-3/8 in) |
| 29. | PY01P01043D3 | [2] | CABLE TIE,188mm L | KOBWire Ties -- 188mm Long |
| 30. | 2444Z2891 | [1] | HYD CONNECTOR | KOB(Incls. O-Ring ZD12P01400) |
| 31. | PU13E01002D9 | [1] | TUBE | KOB300mm Long (11-13/16 in) |
| 32. | YN64H01048P1 | [1] | TEE,90 Degree, PF 3/8" x PF 3/8", O-Ring | KOB(Incls. O-Ring ZD12P01400) |
| 33. | HH35X16016G1 | [2] | 90 ELBOW | KOB90° -- (Incls. O-Ring ZD12P02900) |
| 34. | YX06H01003D1 | [1] | HOSE | KOB760mm Long (29-59/64 in) |
| 35. | ZS28C10030 | [2] | SCREW,Hex Socket Head, M10 x 30mm | KOBM10x1.50x30mm |
| 36. | 2418Z1333D27 | [1] | PROTECTIVE SLEEVE,19.5mm ID x 23.8mm OD x 600mm Length | KOBProtective Plastic |
