| . . | YB32H00003F3 | [1] | HYD LINES, RETURN (EXTRA) | |
| . . | YB32H00003F4 | [1] | HYD LINES, RETURN (EXTRA + NIBBLER & BREAKER) | |
| 1. | YB32H01010P1 | [1] | TUBE | KOBTUBE |
| 2. | YB32H01011P1 | [1] | ELBOW | KOBTUBE |
| 3. | YB32H01003P1 | [1] | RIGID TUBE | KOBTUBE |
| 4. | YB32H01004P1 | [1] | RIGID TUBE | KOBTUBE |
| 5. | ZX22M08094 | [1] | HOSE | KOB940mm Long (37 in) |
| 6. | ZX32M08210 | [1] | FLEXIBLE HOSE | KOB |
| 7. | ZX32M08270 | [1] | HOSE | KOB |
| 8. | LC32H01013D3 | [1] | HOSE | KOB1900mm Long (74-13/16 in) |
| 9. | ZG15F04300 | [3] | COUPLING | KOB |
| 9-3. | ZG15G04300 | [2] | GASKET,43mm ID x 58mm OD | KOB Superseded by part number: R44P0089D7S3 |
| 10. | R44P0089D8 | [2] | ELASTIC JOINT,101mm ID x 148.8mm OD x 165.1mm L | KOB |
| 10-3. | R44P0089D8S3 | [2] | GASKET | KOB |
| 11. | ZG15F05100 | [1] | COUPLING | KOB |
| 11-3. | ZG15G05100 | [2] | GASKET,50.85mm ID x 67.20mm OD | KOB Superseded by part number: R44P0089D4S3 |
| 12. | YN21V00008F1 | [1] | HYDRAULIC VALVE | KOB Superseded by part number: YN21V00013F1 |
| 13. | YN21V00007F1 | [1] | CHECK VALVE | KOB |
| 14. | YB32H01006P1 | [3] | SUPPORT | KOBSUPPORT |
| 15. | YB32H01007P1 | [1] | SUPPORT | KOBSUPPORT |
| 16. | YB32H01015P1 | [2] | SUPPORT | KOBSUPPORT |
| 17. | YB32H01013P1 | [1] | SUPPORT | KOBSUPPORT |
| 18. | 2432T5299 | [3] | CLAMP | KOB |
| 19. | YN32H01035P1 | [2] | CLAMP | KOB |
| 20. | YN32H01066P1 | [3] | CLAMP | KOB94x38x31mm |
| 21. | YN32H01010P1 | [1] | CLAMP | KOBSingle -- 97x38x35mm |
| 22. | ZD11G04500 | [1] | O-RING,44.40mm ID x 50.60mm OD x 3.10mm | KOBID 44.40 ± 0.41 x OD 50mm |
| 23. | YV03H01039P1 | [2] | CONNECTION | KOB1" PF x 3/4" PF x 55.5mm Long (Incls. O-Ring ZD12P02400) |
| 23-1. | ZD12P02400 | [1] | O-RING | KOBID 23.70 ± 0.24 x OD 30mm |
| 25. | 2444T2682 | [1] | HYD CONNECTOR | KOBCONNECTOR |
| 25-1. | ZD12P02400 | [1] | O-RING | KOBID 23.70 ± 0.24 x OD 30mm |
| 26. | 2444R596D3 | [1] | ELBOW | KOB90° -- 1/2" PF |
| 28. | 2444Z2360 | [1] | TEE | KOB(2) 1/2" PF x 3/8" PF x 64mm Long (Incls. O-Ring ZD12P01400) |
| 28-1. | ZD12P01400 | [1] | O-RING | KOBID 13.80 ± 0.19 x OD 18mm |
| 29. | 2444Z2686 | [1] | TEE | KOB |
| 30. | YN02B01031D2 | [3] | SPACER | KOB |
| 31. | ZC46X25011 | [1] | CLIP | KOBClamp, Single Line -- ID 25.5mm |
| 32. | ZC46X31014 | [2] | CLIP | KOBClamp -- Ø31mm Single Cable |
| 33. | YN20M01046DJ | [1] | PROTECTIVE SLEEVE,22.10mm ID x 27.00mm OD x 1000.00mm | KOBProtective Plastic |
| 34. | YN03H01075P1 | [2] | BUSHING,21mm ID x 39mm OD x 50mm L | KOBSplit -- ID 21 x OD 31 x 50mm Long |
| 35. | 2414Z199D100 | [1] | PROTECTIVE SLEEVE | KOBHose -- 1000mm Long (39-3/8 in) |
| 36. | ZS18C10025 | [1] | SCREW,Hex, M10 x 25mm | KOBM10x1.50x25mm |
| 37. | ZS18C10030 | [1] | SCREW,Hex, M10 x 30mm | KOBM10x1.50x30mm |
| 38. | ZS18C10055 | [3] | SCREW,Hex, M10 x 55mm | KOBM10x1.50x55mm |
| 39. | ZS18C10090 | [4] | SCREW,Hex, M10 x 90mm | KOBM10x1.50x90mm |
| 40. | ZS18C12025 | [3] | SCREW,Hex, M12 x 25mm | KOBM12x1.75x25mm |
| 41. | ZS18C12030 | [12] | SCREW,Hex, M12 x 30mm | KOBM12x1.75x30mm |
| 42. | ZS18C12035 | [2] | SCREW,Hex, M12 x 35mm | KOBM12x1.75x35mm |
| 43. | ZS18C12065 | [4] | SCREW,Hex, M12 x 65mm | KOBM12x1.75x65mm |
| 44. | ZW16H10000 | [11] | WASHER | KOBID 11 x OD 24 x Th 3.2mm |
| 45. | ZW16H12000 | [25] | WASHER | KOBID 13 x OD 26 x Th 3.2mm |
| 46. | ZN18C10008 | [2] | NUT | KOBM10x1.50mm |
| 47. | ZN18C12010 | [4] | NUT | KOBM12x1.75mm |
| 48. | ZC48X22014 | [1] | CLIP | KOBClamp, Double -- Ø22x81mm Long |
| 49. | YN20M01046D7 | [1] | PROTECTIVE SLEEVE,22.10mm ID x 27.00mm OD x 1100.00mm | KOBProtective Plastic |
| 50. | ZE72X16000 | [1] | PLUG | KOB(Incls. O-Ring ZD12P02900) |
| 50-1. | ZD12P02900 | [1] | O-RING | KOBID 28.70 ± 0.29 x OD 35mm |
| 51. | YN20M01046DU | [1] | PROTECTIVE SLEEVE,22.10mm ID x 27.00mm OD x 750.00mm | KOBProtective Plastic |
| 52. | ZC46X38014 | [1] | CLIP | KOBClamp -- Ø38.1mm Single Cable |
| 53. | YN64H01018P1 | [1] | GROMMET | KOB |
| 54. | PY01P01043D6 | [3] | CABLE TIE,4.80mm W x 383mm L | KOBWire Ties -- 368mm Long |
| 55. | YN20M01046D8 | [1] | PROTECTIVE SLEEVE,22.10mm ID x 27.00mm OD x 1400.00mm | KOBProtective Plastic |
| 56. | HH25R12012G4 | [2] | HYD CONNECTOR | KOB(Incls. O-Ring ZD12P02400) |
| 57. | ZH32X08000 | [1] | 90 ELBOW,Male, 30 Degree Fl, PF 1/2" x PF 1/2", O-Ring | KOBElbow, 90° -- 1/2"PT (Incls. O-Ring ZD12P01800) |
| 58. | ZH32X08012 | [1] | 90 ELBOW,Male, 30 Degree Fl, PF 1/2" x PF 3/4", O-Ring | KOB90° -- 1/2"PFx3/4"PFx66mm Long (Incls. O-Ring ZD12P02400) |
| 59. | HH55Q12012G2 | [1] | TEE | KOB3/4"PFx86mm Long (Incls. O-Ring ZD12P02400) |
| 60. | ZX23M08200 | [1] | HOSE | KOBHOSE |
| 61. | YN20M01046D5 | [1] | PROTECTIVE SLEEVE,22.10mm ID x 27.00mm OD x 350.00mm | KOBProtective Plastic |
| 62. | YB32H01014P1 | [1] | SUPPORT | KOBSUPPORT |
| 63. | 2420T2948D20 | [1] | U-BOLT | KOBM08x1.25x ID 44x 80mm Long |
| 64. | ZN18C08007 | [4] | NUT | KOBM08x1.25mm |
| . . | ZW16H08000 | [2] | WASHER | KOBID 08 x OD 18 x Th 3.2mm |
