| 1. |
84037900
|
[1] |
SUPPORT
|
ZED
|
| 2. |
84037899
|
[2] |
DRIVEN SPROCKET,12T
|
ZED
|
| 3. |
210053
|
[4] |
TAPERED BEARING,40mm ID x 80mm OD x 18mm W
|
ZED
Superseded by part number: 87668909
|
| 4. |
84039090
|
[4] |
RING,40mm ID x 77.5mm OD x 0.3mm Thk
|
ZED
|
| 5. |
84037898
|
[4] |
BUSHING,40mm ID x 60mm OD x 27.7mm L
|
ZED
|
| 6. |
84037903
|
[1] |
IDLER LEVER
|
ZED
|
| 7. |
9838253
|
[4] |
WASHER,40.5mm ID x 65mm OD x 2.99mm Thk
|
ZED
|
| 8. |
84078078
|
[1] |
SHAFT
|
ZED
|
| 9. |
84039507
|
[1] |
BRACKET
|
ZED
|
| 9. |
48037217
|
[1] |
SUPPORT
|
ZED
, Start Serial: D160
|
| 10. |
84814384
|
[2] |
BRACKET
|
ZED
|
| 11. |
84037939
|
[1] |
SHAFT
|
ZED
|
| 12. |
84041797
|
[1] |
THREADED ROD
|
ZED
|
| 13. |
84041795
|
[1] |
WASHER,26mm ID x 82mm OD x 10mm Thk
|
ZED
|
| 14. |
84011609
|
[1] |
INSULATOR BLOCK
|
ZED
|
| 15. |
84041794
|
[1] |
SUPPORT
|
ZED
|
| 16. |
84078080
|
[1] |
SHAFT
|
ZED
|
| 17. |
84510214
|
[1] |
PLATE
|
ZED
|
| 18. |
43168
|
[4] |
BOLT,Hex, M16 x 40mm, Cl 8.8
|
NH
Superseded by part number: 86509867
|
| 19. |
378246
|
[4] |
WASHER,17mm ID x 34mm OD x 3mm Thk
|
ZED
|
| 20. |
100020
|
[4] |
NUT,M16 x 2.0, Cl 8
|
NH
|
| 21. |
140048
|
[4] |
BELLEVILLE WASHER,M16 Bolt Size x 32mm OD x 2.8mm Thk
|
NH
|
| 22. |
442203
|
[2] |
WASHER,41mm ID x 50mm OD x 0.91mm Thk
|
ZED
|
| 23. |
543836
|
[2] |
LOCK WASHER
|
ZED
Superseded by part number: 80543836
|
| 24. |
543835
|
[2] |
LOCK NUT
|
ZED
Superseded by part number: 80543835
|
| 25. |
370003
|
[4] |
SNAP RING,M30, External
|
NH
|
| 26. |
300633
|
[2] |
SNAP RING,M80, Internal
|
NH
Superseded by part number: 80300633
|
| 27. |
412180
|
[1] |
NUT,M20 x 2.5, Cl 8
|
ZED
Superseded by part number: 9672396
|
| 28. |
86629541
|
[9] |
BOLT,Hex, M12 x 1.75 x 40mm, Cl 8.8
|
NH
|
| 29. |
140046
|
[5] |
BELLEVILLE WASHER,M12 Bolt Size x 27mm OD x 1.8mm Thk
|
NH
|
| 30. |
9706685
|
[5] |
NUT,M12 x 1.75, Cl 8
|
NH
|
| 31. |
394630
|
[4] |
WASHER,13mm ID x 28mm OD x 4mm Thk
|
NH
Superseded by part number: 86625256
|
| 32. |
86507486
|
[1] |
CARRIAGE BOLT,M8 x 1.25 x 20mm, Cl 8.8
|
NH
|
| 33. |
322358
|
[1] |
BELLEVILLE WASHER,M8 Bolt Size x 18mm OD x 1.4mm Thk
|
NH
|
| 34. |
9706690
|
[1] |
NUT,M8 x 1.25, Cl 8
|
NH
Superseded by part number: 43362
|
| 35. |
87556072
|
[1] |
NUT,Flng, 11.8mm OD x 19.8mm L
|
ZED
|
| 36. |
120104
|
[1] |
BOLT,Hex, M8 x 1.25 x 20mm, Cl 8.8
|
NH
|
| 37. |
84563354
|
[1] |
COVER PLATE
|
ZED
|
| 38. |
48028274
|
[1] |
COVER
|
ZED
, Start Serial: D160
|
| 39. |
43140
|
[1] |
BOLT,Hex, M10 x 1.5 x 30mm, Cl 8.8
|
NH
, Start Serial: D160
|
| 40. |
140045
|
[1] |
BELLEVILLE WASHER,M10 Bolt Size x 22mm OD x 1.6mm Thk
|
NH
, Start Serial: D160
|
