| . . | YF32H00001F3 | [1] | HYD LINES, RETURN (NIBBLER & BREAKER + DOZER. EXTRA) | |
| . . | YF32H00001F4 | [1] | HYD LINES, RETURN (DOZER, EXTRA) | |
| 2. | YN32H01079P1 | [1] | ELBOW | KOB |
| 3. | 2444R596D3 | [1] | ELBOW | KOB90° -- 1/2" PF |
| 4. | YN32H01129P1 | [1] | RIGID TUBE | KOB |
| 5. | YN32H01130P1 | [1] | RIGID TUBE | KOB |
| 6. | ZX32M12190 | [1] | FLEXIBLE HOSE | KOB |
| 7. | ZX32M12250 | [1] | FLEXIBLE HOSE | KOB |
| 8. | ZX22M08100 | [1] | HOSE | KOB |
| 9. | ZX32M08210 | [1] | FLEXIBLE HOSE | KOB |
| 10. | ZG15F05100 | [1] | COUPLING | KOB |
| 10-3. | ZG15G05100 | [2] | GASKET,50.85mm ID x 67.20mm OD | KOB Superseded by part number: R44P0089D4S3 |
| 11. | R44P0089D8 | [2] | ELASTIC JOINT,101mm ID x 148.8mm OD x 165.1mm L | KOB |
| 11-3. | R44P0089D8S3 | [2] | GASKET | KOB |
| 12. | ZG15F04300 | [4] | COUPLING | KOB |
| 12-3. | ZG15G04300 | [2] | GASKET,43mm ID x 58mm OD | KOB Superseded by part number: R44P0089D7S3 |
| 13. | YN21V00008F1 | [1] | HYDRAULIC VALVE | KOBASSY, CHECK Superseded by part number: YN21V00013F1 |
| 14. | YN21V00007F1 | [1] | CHECK VALVE | KOBASSY |
| 15. | YN32H01063P1 | [1] | SUPPORT | KOB |
| 16. | YN32H01131P1 | [1] | SUPPORT | KOB |
| 17. | YN32H01064P1 | [1] | SUPPORT | KOB |
| 18. | YN32H01134P1 | [1] | PLATE | KOB |
| 19. | YN32H01051P1 | [2] | SUPPORT | KOB |
| 20. | ZH42X12016 | [1] | 45 ELBOW,Male, 30 Degree Fl, PF 3/4" x PF 1", O-Ring | KOB |
| 20-1. | ZD12P02900 | [1] | O-RING | KOBID 28.70 ± 0.29 x OD 35mm |
| 21. | ZE72X16000 | [1] | PLUG | KOB(Incls. O-Ring ZD12P02900) |
| 21-1. | ZD12P02900 | [1] | O-RING | KOBID 28.70 ± 0.29 x OD 35mm |
| 22. | YN32H01080P1 | [1] | ELBOW | KOBTUBE |
| 23. | 2444Z2360 | [1] | TEE | KOB(2) 1/2" PF x 3/8" PF x 64mm Long (Incls. O-Ring ZD12P01400) |
| 23-1. | ZD12P01400 | [1] | O-RING | KOBID 13.80 ± 0.19 x OD 18mm |
| 24. | HH55X12012G3 | [1] | TEE | KOB |
| 24-1. | ZD12P02400 | [1] | O-RING | KOBID 23.70 ± 0.24 x OD 30mm |
| 25. | 2432T5299 | [2] | CLAMP | KOB |
| 26. | YN02B01031D2 | [2] | SPACER | KOB |
| 27. | 2414Z199D100 | [1] | PROTECTIVE SLEEVE | KOBHose -- 1000mm Long (39-3/8 in) |
| 28. | 2420T2948D20 | [6] | U-BOLT | KOBM08x1.25x ID 44x 80mm Long |
| 29. | ZC46X31014 | [1] | CLIP | KOBClamp -- Ø31mm Single Cable |
| 30. | YW05P01025P1 | [1] | CLIP | KOBClamp -- Ø54x92mm Long |
| 31. | ZD11G04500 | [1] | O-RING,44.40mm ID x 50.60mm OD x 3.10mm | KOBID 44.40 ± 0.41 x OD 50mm |
| 32. | YT68H01013D2 | [1] | RIGID TUBE | KOBID 28.2 x OD 34 x 350mm |
| 33. | ZS18C10055 | [2] | SCREW,Hex, M10 x 55mm | KOBM10x1.50x55mm |
| 34. | HS18C10110G1 | [4] | SCREW | KOBCAP |
| 35. | ZS18C12025 | [5] | SCREW,Hex, M12 x 25mm | KOBM12x1.75x25mm |
| 36. | ZS18C12030 | [5] | SCREW,Hex, M12 x 30mm | KOBM12x1.75x30mm |
| 37. | ZS18C12035 | [4] | SCREW,Hex, M12 x 35mm | KOBM12x1.75x35mm |
| 38. | ZW16H08000 | [12] | WASHER | KOBID 08 x OD 18 x Th 3.2mm |
| 39. | ZW16H10000 | [8] | WASHER | KOBID 11 x OD 24 x Th 3.2mm |
| 40. | ZW16H12000 | [18] | WASHER | KOBID 13 x OD 26 x Th 3.2mm |
| 41. | ZN18C08007 | [24] | NUT | KOBM08x1.25mm |
| 42. | ZN18C10008 | [1] | NUT | KOBM10x1.50mm |
| 43. | ZN18C12010 | [2] | NUT | KOBM12x1.75mm |
| 44. | ZS18C12065 | [1] | SCREW,Hex, M12 x 65mm | KOBM12x1.75x65mm |
| 45. | YN32H01010P1 | [1] | CLAMP | KOBSingle -- 97x38x35mm |
| 46. | YT68H01013D4 | [2] | RIGID TUBE | KOBID 28.2 x OD 34 x 1500mm |
| 47. | ZC46X38014 | [1] | CLIP | KOBClamp -- Ø38.1mm Single Cable |
| 48. | YN03H01074P1 | [1] | BUSHING | KOB |
| 49. | YN32H01109P1 | [1] | SUPPORT | KOB |
| 50. | YN32H01066P1 | [1] | CLAMP | KOB94x38x31mm |
| 51. | ZS18C12060 | [1] | SCREW,Hex, M12 x 60mm | KOBM12x1.75x60mm |
| 52. | YN32H01120P1 | [1] | SUPPORT | KOB |
| 53. | YN20M01046DC | [1] | PROTECTIVE SLEEVE,22.10mm ID x 27.00mm OD x 1600.00mm | KOBProtective Plastic |
| 54. | ZS18C10025 | [1] | SCREW,Hex, M10 x 25mm | KOBM10x1.50x25mm |
| 55. | YN32H01091P1 | [1] | TUBE | KOB |
| 56. | ZH32X12000 | [1] | 90 ELBOW,Male, 30 Degree Fl, PF 3/4" x PF 3/4", O-Ring | KOBElbow, 90° -- 3/4 PF (Incls. O-Ring 237-6012) |
| 56-1. | ZD12P02400 | [1] | O-RING | KOBID 23.70 ± 0.24 x OD 30mm |
| 57. | ZX23M12185 | [1] | HOSE | KOBHOSE |
