纽荷兰零件查询(E235BSRLC) - CRAWLER EXCAVATOR ASN YU05-02001 (01-006) - RADIATOR INSTAL New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
949 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YB05P00014F1 | [1] | RADIATOR INSTAL | |
| . . | YB05P00007F1 | [1] | RADIATOR INSTAL | |
| A1. | YB05P01129P1 | [1] | STAY | KOBSTAY |
| A2. | YB05P01128P1 | [1] | STAY | KOBSTAY |
| A3. | ZM73C12035 | [8] | BOLT,M12x35mm - Course Thread | KOBSEMS |
| . . | YB05P00018F1 | [1] | RADIATOR ASSY | |
| B1. | YB05P00019F1 | [1] | RADIATOR | KOBASSY, SEE FIG. 01-008 |
| B2. | YB05P01154F1 | [1] | PLATE | KOBASSY |
| B2-1. | YB05P01155P1 | [1] | PLATE | KOB |
| B2-2. | YB05P01137P1 | [1] | FOAM INSULATION | KOB |
| B2-3. | YB05P01138P1 | [1] | FOAM INSULATION | KOB |
| B2-4. | YB05P01156P1 | [3] | FOAM INSULATION | KOB |
| B2-5. | YB05P01157P1 | [1] | FOAM INSULATION | KOB |
| B2-6. | YB05P01158P1 | [1] | FOAM INSULATION | KOB |
| B2-7. | YZ21C01094DH | [1] | WEATHERSTRIP | KOB |
| B4. | YB05P01116P1 | [1] | FOAM INSULATION | KOB Superseded by part number: YB05P01116P2 |
| B5. | YB05P01117P1 | [1] | RUBBER BAND | KOBRUBBER |
| B6. | YB05P01118P1 | [1] | RUBBER BAND | KOB |
| B7. | YB05P01119P1 | [1] | RUBBER BAND | KOB |
| B8. | YN05P01355P1 | [2] | O-RING,44.7mm ID x 51.7mm OD x 3.5mm | KOB |
| B10. | ZM73C08020 | [4] | BOLT,M8x20mm - Course Thread | KOBM08x1.25x20mm (Incls. Washer) |
| B11. | YB05P01142P1 | [1] | FOAM INSULATION | KOB |
| B3. | VH834601510A | [1] | SWITCH | KOBSWITCH ASSY, LEVEL WARNING, HINO "Engine Parts" Superseded by part number: VHS834601510 |
| B9. | VH985119116A | [1] | O-RING | KOBO-RING, HINO "Engine Parts" Superseded by part number: VHSZ30119013 |
