| . . | NSS | [1] | NOT SOLD SEPARAT | CONHYDR LINES, UPP |
| . . | YT03H00029F2 | [1] | HYDR LINES, UPP | |
| A1. | 2444Z3713 | [2] | HYD CONNECTOR | KOB(Incls. O-Ring ZD12P01800) |
| A1-1. | ZD12P01800 | [1] | O-RING | KOBID 17.8mm x OD 20.2mm |
| A2. | ZH22X08000 | [3] | HYD CONNECTOR | KOB(Incls. O-Ring ZD12P01800) |
| A3. | ZH32X06008 | [2] | 90 ELBOW,Male, 30 Degree Fl, PF 3/8" x PF 1/2", O-Ring | KOB90° -- 3/8"PFx1/2"PFx40mm Long (Same as ZD12P02400) |
| A4. | LE03H01213P1 | [1] | TEE | KOB |
| A4-1. | ZD12P01800 | [1] | O-RING | KOBID 17.8mm x OD 20.2mm |
| A5. | ZE72X04000 | [1] | PLUG | KOB(PF 1/4) (Incls. O-Ring ZD12P01100) |
| A6. | ZX25M06050 | [2] | HOSE | KOBHOSE |
| A7. | ZX25M06066 | [1] | HOSE | KOB |
| A8. | ZX45M08150 | [1] | HOSE | KOB1500mm Long (59-1/16 in) |
| A9. | YN20M01046D2 | [1] | PROTECTIVE SLEEVE,22.10mm ID x 27.00mm OD x 1200.00mm | KOBProtective Plastic |
| A10. | HH55Q04004G1 | [1] | TEE,1/4" ORB x 1/4" JIC x 1/4" JIC | KOB1/4" PF (Incls. O-Ring ZD12P01100) |
| A11. | ZX35M04030 | [1] | HOSE | KOB300mm Long (11-13/16 in) |
| A12. | ZX25M06060 | [1] | HOSE | KOB |
| A13. | HH55Q08008G3 | [2] | TEE,PF 1/2" x PF 1/2", O-Ring | KOB(PF 1/2) (Incls. O-Ring ZD12P01800) |
| A13-1. | ZD12P01800 | [1] | O-RING | KOBID 17.8mm x OD 20.2mm |
| A15. | ZH42X04000 | [1] | 45 ELBOW,Male, 30 Degree Fl, PF 1/4" x PF 1/4", O-Ring | KOBElbow, 45° -- (Incls. O-Ring 237-6004) |
| A16. | 2418Z1333D5 | [2] | PROTECTIVE SLEEVE,19.5mm ID x 23.8mm OD x 400mm Length | KOB |
| A17. | 2444Z2525 | [1] | HYD CONNECTOR | KOB1/4"PFx35mm Long (Incls. O-Ring ZD12P01100) Superseded by part number: 72217408 |
| A17-1. | ZD12P01100 | [1] | O-RING | KOBID 10.8mm x OD 13.2mm |
| A18. | ZH22X04000 | [1] | HYD CONNECTOR,1/4" NPT x 1/4" NPT | KOB1/4"PFx36mm Long (Incls. O-Ring ZD12P01100) |
| A19. | 2444T3427 | [1] | HYD CONNECTOR | KOB |
| A19-1. | ZD12P01800 | [1] | O-RING | KOBID 17.8mm x OD 20.2mm |
| A20. | ZA23F15006 | [2] | HYD CONNECTOR | KOB3/8"PF - M22x1.50 x 37mm Long (No O-Ring supplied) |
| A21. | ZA33F15008 | [2] | ELBOW | KOB |
| A22. | ZA33F18006 | [1] | ELBOW | KOB |
| A23. | ZA33F18008 | [1] | ELBOW | KOB |
| A24. | ZH42X06000 | [2] | 45 ELBOW,Male, 30 Degree Fl, PF 3/8" x PF 3/8", O-Ring | KOB45° -- (Incls. O-Ring 237-6006) |
| A25. | ZD12P01400 | [3] | O-RING | KOBID 13.80 ± 0.19 x OD 18mm |
| A26. | ZD12P01800 | [3] | O-RING | KOBID 17.8mm x OD 20.2mm |
| A27. | YT03H01045P1 | [1] | TUBE | KOB |
| A28. | YT03H01046P1 | [1] | TUBE | KOB |
| A29. | YT03H01047P1 | [1] | TUBE | KOB |
| A30. | YT03H01044P1 | [1] | BRACKET | KOB |
| A31. | YT35V00007F2 | [1] | SOLENOID VALVE | KOBASSY |
| A32. | ZW16X10000 | [2] | WASHER | KOBID 10 x OD 21 x Th 2.0mm |
| A33. | ZS18C10025 | [2] | SCREW,Hex, M10 x 25mm | KOBM10x1.50x25mm |
| A34. | ZW26X06000 | [2] | LOCK WASHER | KOBID 06 x OD 07 x Th 1.5mm |
| A35. | ZS28C06020 | [2] | SCREW,Hex Socket Head, M6 x 20mm | KOBM06x1.0x20mm |
| A36. | ZN18C06005 | [2] | NUT | KOBM06x1.0mm |
| A37. | HH25R08008G1 | [1] | HYD CONNECTOR | KOB1/2" PF (Incls. O-Ring ZD12P01800) 106mm Long |
| A37-1. | ZD12P01800 | [1] | O-RING | KOBID 17.8mm x OD 20.2mm |
| A38. | 2418Z1333D4 | [2] | PROTECTIVE SLEEVE,19.5mm ID x 23.8mm OD x 500mm Length | KOB |
| A39. | HH35R08006G1 | [1] | ELBOW | KOB |
| A40. | LC52S00012P1 | [1] | SENSOR | KOBSENSOR, PRESS (H.P.) Superseded by part number: YY52S00033F1 |
| A40-2. | ZD12P01400 | [1] | O-RING | KOBID 13.80 ± 0.19 x OD 18mm |
| . . | YT19H00015F1 | [1] | HYDR LINES, SWIVEL | |
| B1. | 2444Z2338 | [2] | 90 ELBOW | KOB90° -- (1/4" PFx3/8" PF), (Incls. O-Ring ZD12P01100) |
| B1-1. | ZD12P01100 | [1] | O-RING | KOBID 10.8mm x OD 13.2mm |
| B2. | ZD12P01800 | [4] | O-RING | KOBID 17.8mm x OD 20.2mm |
| B3. | YT19H01015P1 | [3] | ELBOW | KOB Superseded by part number: ZA38F18008 |
| B4. | YT19H01016P1 | [1] | CONNECTION | KOB Superseded by part number: ZA28F18008 |
| B4-1. | ZD12P01800 | [1] | O-RING | KOBID 17.8mm x OD 20.2mm |
| B5. | YR03H01121P1 | [2] | CONNECTION | KOB(Incls. O-Ring ZD12P01800) |
| B5-1. | ZD12P01800 | [1] | O-RING | KOBID 17.8mm x OD 20.2mm |
| B6. | YR19H01004P1 | [1] | CONNECTION | KOB |
| B6-1. | ZD12P01400 | [1] | O-RING | KOBID 13.80 ± 0.19 x OD 18mm |
| B7. | YT19H01006P1 | [1] | TUBE | KOB |
| B8. | ZE72X04000 | [1] | PLUG | KOB(PF 1/4) (Incls. O-Ring ZD12P01100) |
| B8-1. | ZD12P01100 | [1] | O-RING | KOBID 10.8mm x OD 13.2mm |
| B9. | ZH32X06000 | [2] | 90 ELBOW,Male, 30 Degree Fl, PF 3/8" x PF 3/8", O-Ring | KOBElbow, 90° -- (Incls. O-Ring ZD12P01400) Alternate O-Ring 237-6006 |
| B9-1. | ZD12P01400 | [1] | O-RING | KOBID 13.80 ± 0.19 x OD 18mm |
| B10. | 2444Z2891 | [1] | HYD CONNECTOR | KOB(Incls. O-Ring ZD12P01400) |
| B10-1. | ZD12P01400 | [1] | O-RING | KOBID 13.80 ± 0.19 x OD 18mm |
| B11. | ZH32X04000 | [2] | 90 ELBOW,Male, 30 Degree Fl, PF 1/4" x PF 1/4", O-Ring | KOBElbow, 90° -- PF 1/4, (Incls. O-Ring 237-6004) |
| B11-1. | ZD12P01100 | [1] | O-RING | KOBID 10.8mm x OD 13.2mm |
| B12. | 2444Z2525 | [1] | HYD CONNECTOR | KOB1/4"PFx35mm Long (Incls. O-Ring ZD12P01100) Superseded by part number: 72217408 |
| B12-1. | ZD12P01100 | [1] | O-RING | KOBID 10.8mm x OD 13.2mm |
