神钢零件查询(EXTRA) - AND BREAKER ATTACHMENT - K907 II ASN YN0101 & K907LC II ASN YQ0101 (1/88-12/06) (04-001) - INSTAL HYD LINES, BOOM, 5.6M (EXTRA) Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
202 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 24100J10514F1 | [1] | HYD LINES ASSY BOOM, 5.6M | HYD LINES ASSY BOOM, 5.6M |
| 1. | 2418P20196D2 | [1] | TUBE | TUBE |
| 2. | 2418P20196D1 | [1] | TUBE | TUBE |
| 3. | 2418P20191D2 | [1] | TUBE | TUBE |
| 4. | 2418P20191D1 | [1] | TUBE | TUBE |
| 5. | 2444R950D1 | [2] | HOSE | KOB |
| 6. | 2432T3993 | [12] | CLAMP | KOBDouble Line -- 95x38x19mm Hole Only |
| 7. | 2432T3994 | [12] | CLAMP | KOBDouble Line -- 95x38x19mm Threaded M12 |
| 8. | ZA23B18000 | [2] | HYD CONNECTOR | KOB |
| 9. | ZS13C12040 | [12] | SCREW | KOBM12x1.75x40mm Superseded by part number: ZS18C12040 |
| 10. | ZW22X12000 | [12] | LOCK WASHER | KOBID 12 x OD 21.5 x Th 3.0mm Superseded by part number: ZW26X12000 |
| 11. | 2414Z199D025 | [4] | PROTECTIVE SLEEVE | KOBHose -- 250mm Long (9-27/32 in) |
