神钢零件查询(NIBBLER) - & BREAKER - SK70SR-1E SHORT RADIUS EXCAVATOR ASN YT02-04001 (4/03-12/04) (06-005[00]) - VALVE INSTALLATION (BREAKER, NIBBLER & BREAKER) Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
210 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 0. | YT30V00010F3 | [1] | VALVE | KOBControl Assembly, See Full Model Parts Catalog Superseded by part number: YT30V00010F4 |
| 0-1. | YT30V00007F1 | [1] | CONTROL | KOBValve Assembly |
| 0-1A. | YT30V00017F1 | [1] | VALVE | KOBControl Assembly, See Full Model Parts Catalog Superseded by part number: YT30V00007F1 |
| 0-1B. | ZS23C12065 | [4] | SCREW,Hex Socket Head, M12 x 65mm | KOBM12x1.75x65mm |
| 0-1C. | ZD12P02200 | [4] | O-RING | KOBID 21.80 ± 0.24 x OD 26mm |
| 0-1D. | YN01V00004S006 | [1] | O-RING | KOB |
