纽荷兰零件查询(E235BSRLC) - CRAWLER EXCAVATOR ASN YU05-02001 (01-065) - COMPRESSOR ASSY, AIR New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
578 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YX91V00001F1 | [1] | COMPRESSOR,W/ Pulley | KOBASSY, AIR |
| . . | YX91V00001F1R | [1] | REMAN-COMPRESSOR,W/ Pulley | KOBE235BSRLC, E235BSRNLC, Both ASN YU05-02001, E235BSR ASN YF05-02001 |
| . . | YX91V00001F1C | [1] | CORE-COMPRESSOR | KOBReturn Number |
| 1. | LC91V00001S002 | [1] | PLATE | KOBCORE |
| 2. | YN91V01001S002 | [1] | PLATE | KOB |
| 3. | YN91V01001S003 | [1] | ROTOR | KOB |
| 4. | LC91V00001S004 | [1] | ACCESSORIES | KOB |
| 5. | YN91V01001S005 | [1] | COVER | KOB |
| 6. | YN91V01001S006 | [1] | COVER | KOB |
| 7. | YN91V01001S007 | [1] | RING | KOBASSY |
