| . . | YF02B00054F1 | [1] | BOOM GROUP | |
| A1. | 2444R1117D115 | [1] | HOSE,6.40mm ID x 1150mm L | KOB |
| A2. | 2444R1117D120 | [1] | HOSE,6.40mm ID x 1200mm L | KOB |
| A3. | 2444R1117D210 | [1] | HOSE,6.40mm ID x 2100mm L | KOB |
| A4. | 2444R1117D220 | [1] | HOSE,6.40mm ID x 2200mm L | KOB |
| A5. | 2444R1117D260 | [1] | HOSE,6.4mm ID x 2600mm L | KOB |
| A6. | ZH32Z04000 | [2] | ELBOW | KOB |
| A7. | ZG91S02000 | [6] | LUBE NIPPLE,1/8" NPT x 1/8" NPT | KOBGREASE |
| A8. | 2414Z199D25 | [1] | GUARD | KOBHOSE, GUARD Superseded by part number: 2414Z199D025 |
| . . | YF02B00052F1 | [1] | BOOM | KOBBOOM ASSY, HOE |
| B1. | YF02B00053F1 | [1] | BOOM ASSY, HOE, SEE FIG. 03-002 | |
| B2. | 2445R138D8 | [2] | SEAL,90mm ID x 105mm OD x 4mm Thk | KOBDUST |
| . . | YB02B00059F1 | [1] | BOOM INSTAL | |
| C1. | YB02B01061P1 | [1] | PIN | KOB |
| C2. | YN02B01233P1 | [1] | PIN | KOB |
| C3. | YN02B01234P1 | [1] | SPRING | KOB |
| C4. | B16T0442D53 | [1] | SHIM,92mm ID x 160mm OD x 0.5mm Thk | KOB(0.5) |
| C5. | B16T0442D40 | [1] | SHIM,92mm ID x 160mm OD x 0.9mm Thk | KOB(0.9) |
| C6. | B16T0442D14 | [1] | SHIM,160mm OD x 92mm ID x 1.6mm Thk | KOB(1.6) |
| C7. | B16T0442D15 | [1] | SHIM,160mm OD x 92mm ID x 2.3mm Thk | KOB(2.3) |
| C8. | YN02B01414D1 | [2] | SHIM,92mm ID x 160mm OD x 2mm Thk | KOB(2.0) |
| . . | YF02B00056F1 | [1] | CYLINDER INSTAL | |
| 01. | YF01V00001F1 | [2] | HYDRAULIC CYLINDER | KOBCYLINDER ASSY, BOOM |
| . . | YF02B00057F1 | [1] | CYLINDER INSTAL | |
| D1. | YF02B01063P1 | [2] | PIN | KOBPIN |
| D2. | YN02B01721P1 | [1] | PIN,85mm OD x 776mm L | KOB |
| D3. | ZS18C16030 | [2] | SCREW,Hex, M16 x 30mm | KOBCAP |
| D4. | HS18C16150G2 | [2] | SCREW | KOBCAP |
| D5. | 2418T17550 | [2] | PLATE | KOB |
| D6. | YN02B01108P1 | [2] | BOSS | KOB |
| D7. | ZN18C16013 | [4] | NUT | KOB |
| D8. | ZW16H16000 | [2] | WASHER | KOB |
| D9. | YN02B01417D1 | [2] | SHIM,87mm ID x 140mm OD x 2mm Thk | KOB(2.0) |
| D10. | LQ02B01215D1 | [4] | SHIM | KOB(2.0) |
| D11. | YN02B01109D1 | [1] | SHIM,87mm ID x 120mm OD x 0.5mm Thk | KOB(0.5) |
| D12. | YN02B01109D2 | [1] | SHIM,87mm ID x 120mm OD x 0.9mm Thk | KOB(0.9) |
| D13. | YN02B01109D4 | [1] | SHIM,87mm ID x 120mm OD x 1.6mm Thk | KOB(1.6) |
| D14. | B16T0442D87 | [1] | SHIM,160mm OD x 97mm ID x 0.5mm Thk | KOBSHIM (0.5) |
| D15. | B16T0442D86 | [1] | SHIM,160mm OD x 97mm ID x 0.9mm Thk | KOBSHIM (0.9) |
| D16. | B16T0442D35 | [1] | SHIM,160mm OD x 97mm ID x 1.6mm Thk | KOBSHIM (1.6) |
| . . | YN02B00407F1 | [1] | CYLINDER INSTAL | |
| 02. | YN01V00175F1 | [1] | CYLINDER,Double Acting, 95mm Rod, 1558mm Stroke | KOBASSY, ARM |
| . . | YN01V00175F1R | [1] | REMAN-HYD CYLINDER | KOBE235BSR ASN YF05-02001, E235BSRLC, E235BSLNLC, BOTH ASN YU05-02001 |
| . . | YN01V00175F1C | [1] | CORE-HYD CYLINDER | KOBReturn Number |
| . . | YN02B00367F1 | [1] | CYLINDER INSTAL | |
| E1. | YN02B01722P1 | [1] | PIN,85mm OD x 277mm L | KOB |
| E4. | B16T0442D78 | [1] | SHIM,87mm ID x 140mm OD x 0.5mm Thk | KOB(0.5) |
| E5. | B16T0442D77 | [1] | SHIM,87mm ID x 140mm OD x 0.9mm Thk | KOB(0.9) |
| E6. | B16T0442D62 | [1] | SHIM,87mm ID x 140mm OD x 1.6mm Thk | KOB(1.6) |
