| 1. | ZH32X04000 | [15] | 90 ELBOW,Male, 30 Degree Fl, PF 1/4" x PF 1/4", O-Ring | KOBElbow, 90° -- (PF 1/4)(Incls. O-Ring 237-6004), (F2 Only) |
| . . | ZH32X04000 | [13] | 90 ELBOW,Male, 30 Degree Fl, PF 1/4" x PF 1/4", O-Ring | KOBElbow, 90° -- (PF 1/4)(Incls. O-Ring 237-6004), (F5 Only) |
| 2. | HH55Q04004G1 | [11] | TEE,1/4" ORB x 1/4" JIC x 1/4" JIC | KOB1/4" PF (Incls. O-Ring ZD12P01100) |
| 3. | ZH22X04000 | [19] | HYD CONNECTOR,1/4" NPT x 1/4" NPT | KOB1/4"PFx36mm Long (Incls. O-Ring ZD12P01100), (F2 Only) |
| . . | ZH22X04000 | [18] | HYD CONNECTOR,1/4" NPT x 1/4" NPT | KOB1/4"PFx36mm Long (Incls. O-Ring ZD12P01100), (F5 Only) |
| 4. | 2444T2524 | [5] | HYD CONNECTOR | KOB1/4" PF x 50mm Long (Incls. O-Ring ZD12P01100) |
| 5. | ZX22M06120 | [1] | HOSE ASSY. | KOB1200mm Long (47-1/4in), Serial Range: YT02-04001-YT02-04192 |
| 6. | HH25R06004G2 | [1] | CONNECTION | KOB |
| 7. | 2444R1120D100 | [1] | HOSE | KOB1000mm Long (39-3/8 in) |
| 8. | 2444R1120D120 | [1] | HOSE | KOB1200mm Long (47-1/4in) |
| 9. | 2444R1120D070 | [1] | HOSE | KOB700mm Long (27-1/2 in) |
| 10. | 2444R1120D160 | [1] | HOSE | KOB1600mm Long (63 in) |
| 11. | 2420R349D075 | [2] | HOSE | KOB750mm Long (29-1/2 in) Superseded by part number: 2444R3019D3 |
| 12. | 2420R349D105 | [1] | HOSE,1050.00 mm | KOB1050mm Long (41-21/64 in) |
| 13. | 2420R349D090 | [2] | HOSE,6.35mm ID x 900mm L | KOB900mm Long (35-7/16 in) |
| 14. | 2444Z2525 | [3] | HYD CONNECTOR | KOB1/4"PFx35mm Long (Incls. O-Ring ZD12P01100) Superseded by part number: 72217408 |
| 15. | HH25R04004G3 | [1] | CONNECTION | KOB1/4"PFx72mm Long (Incls. O-Ring ZD12P01100) |
| 16. | HH25R06006G4 | [2] | HYD CONNECTOR | KOB3/8" PF x 105mm Long (Incls. O-Ring ZD12P01400), Serial Range: YT02-04001-YT02-04192 |
| 17. | PY01P01043D6 | [2] | CABLE TIE,4.80mm W x 383mm L | KOBWire Ties -- 368mm Long |
| 18. | ZH42X04000 | [1] | 45 ELBOW,Male, 30 Degree Fl, PF 1/4" x PF 1/4", O-Ring | KOBElbow, 45° -- (Incls. O-Ring 237-6004) |
| 19. | 2444Z2894 | [3] | 90 ELBOW | KOBElbow, 90° -- 1/4" PF (Incls. O-Ring ZD12P01100) |
| 20. | ZH32X06000 | [2] | 90 ELBOW,Male, 30 Degree Fl, PF 3/8" x PF 3/8", O-Ring | KOBElbow, 90° -- (Incls. O-Ring 237-6006), Serial Range: YT02-04001-YT02-04192 |
| . . | ZH32X06000 | [1] | 90 ELBOW,Male, 30 Degree Fl, PF 3/8" x PF 3/8", O-Ring | KOBElbow, 90° -- (Incls. O-Ring 237-6006), Start Serial: YT02-04193 |
| 21. | ZH32X04006 | [3] | 90 ELBOW,Male, 30 Degree Fl, PF 1/4" x PF 3/8", O-Ring | KOBElbow, 90° -- (Incls. O-Ring 237-6006) |
| 22. | 2444R1120D045 | [1] | HOSE | KOB450mm Long (17-23/32 in) |
| 23. | YT21V00002P1 | [3] | CHECK VALVE | KOB |
| 24. | LC52S00011P1 | [4] | SENSOR | KOBPressure (Low Pressure) (Incls. O-Ring ZD12P01100) Superseded by part number: LC52S00019P1 |
| 24-2. | ZD12P01100 | [1] | O-RING | KOBID 10.8mm x OD 13.2mm |
| 25. | ZH22X06000 | [2] | HYD CONNECTOR | KOB(Incls. O-Ring ZD12P01400), Serial Range: YT02-04001-YT02-04192 |
| . . | ZH22X06000 | [1] | HYD CONNECTOR | KOB(Incls. O-Ring ZD12P01400), Start Serial: YT02-04193 |
| 26. | 2444Z3541 | [1] | CONNECTION | KOB1/4" PF x 36mm Long (Incls. O-Ring ZD12P01100) Superseded by part number: 2444Z3759 |
| 27. | HH25X04004G3 | [1] | CONNECTION | KOB |
| 28. | HH55Q06004G3 | [1] | TEE | KOB |
| 29. | 2444R1120D090 | [2] | HOSE | KOB900mm Long (35-7/16 in) |
| 30. | HH55Q06006G1 | [1] | TEE | KOB3/8" PF (Incls. O-Ring ZD12P01400) |
