纽荷兰零件查询(E235BSRNLC) - CRAWLER EXCAVATOR ASN YU05-02001 (03-010) - BUCKET ASSY, STANDARD 0.8 CU.M New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
777 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YN61B00316F1 | [1] | BUCKET ASSY, STD 0. 8M3 | |
| . . | YN61B00317F1 | [1] | BUCKET | KOBBUCKET ASSY.0.8M3 Superseded by part number: YN61B00420F1 |
| 1. | YN61B00260P1 | [1] | BUCKET | |
| 1-17. | YN69B01048D1 | [1] | CUTTING EDGE | KOBEDGE, CUTTING |
| 1-18. | YN61B01011P1 | [5] | ADAPTER | KOB |
| 2. | B12N0006F1 | [3] | TOOTH | KOBASSY |
| 2-1. | B12N0006E1 | [1] | BUCKET TOOTH POINT | KOBPOINT |
| 2-2. | B12N0006E2 | [1] | LOCK PIN | KOBRUBBER Superseded by part number: B12N0006E2MK |
| 2-3. | B12N0006E3 | [1] | PIN | KOBPIN, LOCKING Superseded by part number: 2412Z163K |
| 3. | 2412U113F1 | [2] | TOOTH | KOBASSY |
| 3-1. | 2412U113S1 | [1] | POINT | KOBTOOTH |
| 4. | 2412N289D11 | [1] | BLADE | KOBCUTTER, SIDE Superseded by part number: YN69B00006P1 |
| 5. | 2412N289D21 | [1] | BLADE | KOBCUTTER, SIDE Superseded by part number: YN69B00007P1 |
| 6. | ZS13C24070 | [8] | SCREW | KOBCAP |
| 7. | ZN13C24019 | [8] | NUT | KOB |
| 8. | YB61B01003P1 | [1] | BUSHING | KOB |
| 9. | YB61B01005P1 | [1] | PLATE | KOBPLATE |
| 10. | YB61B01004P1 | [5] | SHIM | KOB(1.0) |
| 11. | 2419T3747D2 | [1] | PIN | KOB |
| 12. | ZS13C16045 | [3] | SCREW | KOBSCREW |
| 13. | YB61B01007P1 | [3] | WASHER | KOB |
