纽荷兰零件查询(E235BSRNLC) - CRAWLER EXCAVATOR ASN YU05-02001 (09-002) - HYD LINES, ARM 2.94M (EXTRA) New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
538 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YN43H00203F1 | [1] | HYDRAULIC EQUIPMENT REEL | KOBHYD LINES, ARM, SEE FIG. 05-012 |
| . . | YN43H00202F1 | [1] | ARM | KOBHYD LINES, ARM |
| A1. | YN43H01675P1 | [1] | TUBE,22.0 mm OD | KOBTUBE |
| A2. | YN43H01676P1 | [1] | TUBE,22.0 mm OD | KOBTUBE |
| A3. | YN43H01669P1 | [1] | BRACKET | KOBBRACKET |
| A4. | YN43H01671P1 | [1] | BRACKET | KOBBRACKET |
| A5. | ZX58N10155 | [2] | HOSE | KOB |
| A7. | ZC26X22011 | [6] | CLAMP | KOB |
| A8. | ZM73C10045 | [6] | BOLT,M10x45mm - Course Thread | KOBSEMS-BOLT |
| A9. | ZS18C16040 | [4] | SCREW,Hex, M16 x 40mm | KOBCAP |
| A10. | ZW16H16000 | [4] | WASHER | KOB |
| . . | LC43H01313F1 | [1] | PLUG ASSY | |
| B1. | ZA82P22000 | [2] | PLUG | KOB |
