神钢零件查询(NIBBLER) - & BREAKER - SK70SR-1E SHORT RADIUS EXCAVATOR ASN YT02-04001 (4/03-12/04) (06-077[02]) - CONTROLLER ASSEMBLY, (YT22E00013FN, YT22E00013FP & YT22E00013FR), PAGE 2 OF 2 Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
123 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 8. | EN24S00008P1 | [2] | RELAY | KOB(FN Only) (5 Spade Relay) |
| . . | EN24S00008P1 | [4] | RELAY | KOB(FP Only) (5 Spade Relay) |
| 14. | ZM61C06012 | [2] | BOLT | KOBM06x1.0x12mm (Incls. Washer & Lockwasher), (FN Only) |
| . . | ZM61C06012 | [4] | BOLT | KOBM06x1.0x12mm (Incls. Washer & Lockwasher), (FP Only) |
| 23. | ZW16X06000 | [2] | WASHER | KOBID 06 x OD 12.5 x Th 1.6mm, (FN Only) Superseded by part number: 86588450 |
| . . | ZW16X06000 | [4] | WASHER | KOBID 06 x OD 12.5 x Th 1.6mm, (FP Only) Superseded by part number: 86588450 |
| 24. | YT14E00014F3 | [1] | Cab Harness, Incls. Refs. 24-8, (FN & FP Only) | |
| 24-8. | YT13E01093P1 | [1] | Harness | |
| 33. | YT14E00014F4 | [1] | Cab Harness, Incls. Refs. 33-8, (FR Only) | |
| 33-8. | YT13E01093P1 | [1] | Harness | |
| 37. | YT22E00008F7 | [1] | CONTROL | KOB(FR Only) |
| 38. | YT22E00008F8 | [1] | CONTROLLER | KOBController, (FN & FP Only) |
