神钢零件查询(NIBBLER) - & BREAKER - SK70SR-1E SHORT RADIUS EXCAVATOR ASN YT02-04001 (4/03-12/04) (06-095[00]) - BOOM HYDRAULIC LINES 3.72M (12FT 2IN) (EXTRA, NIBBLER & BREAKER), (YT42H00068F1) Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
543 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | YT42H01234P1 | [1] | RIGID TUBE | KOB |
| 2. | YT42H01235P1 | [1] | TUBE | KOB |
| 3. | YT42H01015P1 | [1] | RIGID TUBE | KOB |
| 4. | YT42H01074P1 | [1] | RIGID TUBE | KOB |
| 5. | YT42H01264P1 | [1] | TUBE | KOB |
| 6. | YT42H01265P1 | [1] | TUBE | KOB |
| 7. | 24100P1005F1 | [1] | VALVE | KOBAssembly, Selector, Incls. Refs. 7-1 - 7-10 Superseded by part number: 24100P1005F3 |
| 7-1. | 2436P229 | [1] | VALVE BODY | KOB |
| 7-2. | 2436T303 | [1] | VALVE | KOB |
| 7-3. | 2418T8945D1 | [1] | SPACER | KOBID 40 x OD 60 x Th 3.2mm |
| 7-4. | ZR16X04000 | [1] | RING | KOBRetaining -- ID 37 x OD 40 x Th 1.8mm |
| 7-5. | ZS23C06010 | [1] | SCREW,Hex Socket Head, M6 x 10mm | KOBM06x1.0x10mm |
| 7-6. | ZD11G04000 | [2] | O-RING,39.40mm ID x 45.60mm OD x 3.10mm | KOBID 39.40 ± 0.37 x OD 45mm |
| 7-7. | ZD12G04000 | [1] | O-RING,39.40mm ID x 45.60mm OD x 3.10mm | KOBID 39.40 ± 0.37 x OD 45mm |
| 7-8. | ZD75G04000 | [1] | BACK-UP RING | KOBID 40 x OD 45 x Th 1.25mm |
| 7-9. | ZD12G03500 | [1] | O-RING,34.40mm ID x 40.60mm OD x 3.10mm | KOBID 34.40 ± 0.33 x OD 40mm |
| 7-10. | ZD85G03500 | [1] | RING | KOBBack-Up -- ID 35 x OD 40 x Th 1.25mm |
| 8. | YR42H01056P1 | [1] | SUPPORT | KOB |
| 9. | LF42H01009P1 | [1] | BRACKET | KOB |
| 11. | 2444R402D4 | [2] | HYD CONNECTOR | HIT(Incls. O-Ring ZD12P01400) |
| 12. | ZA23F15006 | [2] | HYD CONNECTOR | KOB3/8"PF - M22x1.50 x 37mm Long (No O-Ring supplied) |
| 13. | ZA23F22012 | [1] | HYD CONNECTOR | KOB3/4" PF - M30x1.50x46mm Long |
| 14. | ZA33F22012 | [2] | ELBOW | KOB |
| 15. | ZD12P01400 | [2] | O-RING | KOBID 13.80 ± 0.19 x OD 18mm |
| 16. | ZD12P02400 | [3] | O-RING | KOBID 23.70 ± 0.24 x OD 30mm |
| 17. | ZE72X12000 | [2] | PLUG | KOB(Incls. O-Ring ZD12P02400) |
| 18. | ZC26X22011 | [8] | CLAMP | KOBSingle Line -- 38x29x65mm Long |
| 19. | ZC36X18011 | [1] | CLAMP | KOB |
| 20. | ZC36X22011 | [1] | CLAMP | KOBDouble Line -- 75x38x13mm (Ø24mm) |
| 21. | YT42H01114P1 | [10] | CLAMP | KOB |
| 22. | YT42H01115P1 | [10] | CLAMP | KOB |
| 23. | ZS18C08020 | [8] | SCREW,Hex, M8 x 20mm | KOBM08x1.25x20mm |
| 24. | ZS18C10020 | [2] | SCREW,Hex, M10 x 20mm | KOBM10x1.50x20mm |
| 25. | ZS18C10035 | [11] | SCREW,Hex, M10 x 35mm | KOBM10x1.50x35mm |
| 26. | ZS18C10045 | [8] | SCREW,Hex, M10 x 45mm | KOBM10x1.50x45mm |
| 27. | HS18C10105G2 | [1] | CAPSCREW | KOBSCREW M10x1.50x105mm |
| 28. | ZN18C10008 | [1] | NUT | KOBM10x1.50mm |
| 29. | ZW26X08000 | [8] | LOCK WASHER | KOBID 08 x OD 15 x Th 2.0mm Superseded by part number: 83990583 |
| 30. | ZW26X10000 | [22] | LOCK WASHER | KOBID 10 x OD 18 x Th 2.5mm |
| 31. | ZW16X10000 | [1] | WASHER | KOBID 10 x OD 21 x Th 2.0mm |
