神钢零件查询(NIBBLER) - & BREAKER - SK70SR-1E SHORT RADIUS EXCAVATOR ASN YT02-04001 (4/03-12/04) (06-105[00]) - ARM, 1.65M (5FT 5IN) (EXTRA, NIBBLER & BREAKER), (YT12B00088F3) Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
513 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 2. | YT12B01010P2 | [2] | BUSHING | KOB |
| 3. | LE12B01054P1 | [2] | BUSHING | KOB |
| 4. | YT12B01112P1 | [2] | BUSHING | KOB |
| 6. | NSS | [1] | NOT SOLD SEPARAT | CONArm |
| 6-2. | YT12B01108P1 | [1] | PLATE | KOB Superseded by part number: YT12B01108P2 |
| 6-3. | YT12B01109P1 | [1] | PLATE | KOB Superseded by part number: YT12B01109P2 |
| 6-4. | YT12B01110P1 | [1] | PLATE | KOB |
| 6-5. | 2416T24666 | [2] | BRACKET | KOB |
| 6-6. | YT12B01095P1 | [1] | BLOCK | KOBTapped |
| 6-7. | 2416T10838D3 | [1] | BLOCK | KOBTapped |
