| . . | YN12B00801F1 | [1] | CYLINDER INSTAL | |
| 0. | YN01V00153F1 | [1] | HYDRAULIC CYLINDER | KOBASSY, BUCKET |
| . . | YN01V00153F1R | [1] | REMAN-HYD CYLINDER | KOBE235BSR ASN YF05-02001, E235BSRLC, E235BSRNLC, both ASN YU05-02001 |
| . . | YN01V00153F1C | [1] | CORE-HYD CYLINDER | KOBReturn Number |
| . . | YN12B00654F1 | [1] | CYLINDER INSTAL | |
| A1. | YN12B02218P1 | [1] | PIN,80mm OD x 252mm L | KOB |
| A2. | HS18C16140G2 | [1] | SCREW,M16 x 140mm, Cl 10.9 | KOBCAP |
| A3. | ZN18C16013 | [2] | NUT | KOB |
| A4. | YN12B01601D1 | [2] | SHIM,82mm ID x 140mm OD x 2mm Thk | KOB(2.0) |
| A5. | YN12B01122D1 | [1] | SHIM,82mm ID x 140mm OD x 0.5mm Thk | KOB(0.5) |
| A6. | YN12B01122D2 | [1] | SHIM,82mm ID x 140mm OD x 0.9mm Thk | KOB(0.9) |
| A7. | YN12B01122D3 | [1] | SHIM,82mm ID x 140mm OD x 1.6mm Thk | KOB(1.6) |
| . . | YF43H00021F1 | [1] | HYD LINES, CYLINDER | |
| B1. | YF43H01035P1 | [1] | TUBE | |
| B2. | YF43H01036P1 | [1] | RIGID TUBE | KOBTUBE |
| B3. | YX42H01074P2 | [2] | BAND | KOB |
| B4. | YN43H01639P1 | [1] | BAND | KOB |
| B5. | YF43H01037P1 | [1] | BAND | KOBBAND |
| B6. | YN43H01097P1 | [1] | CLAMP | KOB |
| B7. | YN42H02357P1 | [2] | CLAMP,37mm ID, J Type | KOB Superseded by part number: 87343093 |
| B8. | ZG91S02000 | [1] | LUBE NIPPLE,1/8" NPT x 1/8" NPT | KOBGREASE |
| B9. | ZG91U02000 | [1] | LUBE NIPPLE | KOBGREASE |
| B10. | ZD12P02600 | [1] | O-RING | KOB |
| B11. | ZD12P03400 | [1] | O-RING,0.139" Thk x 1.296" ID, -219, Cl 6, 90 Duro | KOB |
| B12. | ZD12A01800 | [1] | O-RING,1.78mm Thk x 18.77mm ID, Cl 6 | KOB |
| B13. | ZM73C12035 | [2] | BOLT,M12x35mm - Course Thread | KOBSEMS |
| B14. | ZS18C10030 | [4] | SCREW,Hex, M10 x 30mm | KOBCAP |
| B15. | ZS18C10055 | [1] | SCREW,Hex, M10 x 55mm | KOBCAP |
| B16. | ZS28C10030 | [4] | SCREW,Hex Socket Head, M10 x 30mm | KOBCAP |
| B17. | ZS28C12040 | [4] | SCREW,Hex Socket Head, M12 x 40mm | KOBCAP |
| B18. | ZW26X10000 | [4] | LOCK WASHER | KOBID 10 x OD 18 x Th 2.5mm |
| B19. | ZW16H10000 | [1] | WASHER | KOB |
| . . | YF43H00022F1 | [1] | HYD LINES, ARM | |
| C1. | YF43H01039P1 | [1] | BRACKET | |
| C2. | YF43H01040P1 | [1] | BRACKET | |
| C3. | ZX50H12070 | [1] | HOSE ASSY | |
| C4. | ZX60U16084 | [1] | FLEXIBLE HOSE | KOBHOSE ASSY |
| C5. | ZX50H16140 | [1] | HOSE,25.4mm ID x 1400mm L | KOB |
| C6. | ZX50H12135 | [1] | HOSE | KOB |
| C7. | ZG23F12012 | [1] | HYD CONNECTOR | KOB1 3/16" 12UN-3/4" PT x 48mm Long (Incls. O-Ring ZD12P02400) |
| . . | ZD12P02400 | [1] | O-RING | KOB(Part of ZG23F12012), ID 23.70 ± 0.24 x OD 30mm, Not Shown |
| C8. | ZG23F16016 | [1] | HYD CONNECTOR | KOB |
| C9. | ZG33F12012 | [1] | 90 ELBOW,1 3/16"-12 UN x PF 3/4" | KOB |
| C10. | ZG33F16016 | [1] | 90 ELBOW,1 7/16"-12 UN x PF 1" | KOB |
| C11. | ZE13X16000 | [2] | FLANGE | KOBHALF |
| C15. | ZD12A02100 | [2] | O-RING | KOB |
| C17. | ZW26K12000 | [4] | LOCK WASHER | KOB |
