神钢零件查询(NIBBLER) - BREAKER & EXTRA ATTACHMENTS - SK200SR & SK200SRLC (1/01-12/06) (01-010[02]) - HYD LINES, UPP (BREAKER) Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
1001 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YB03H00023F1 | [1] | HYD LINES, UPP | |
| 1. | YB03H01048P1 | [1] | RIGID TUBE | KOBTUBE Superseded by part number: YB03H01052P1 |
| 2. | YB03H01016P1 | [1] | TUBE | KOB |
| 4. | YB03H01032D1 | [1] | HOSE | KOBHOSE |
| 5. | ZE72X12000 | [1] | PLUG | KOB(3/4" PF) (Incls. O-Ring ZD12P02400) |
| 5-1. | ZD12P02400 | [1] | O-RING | KOBID 23.70 ± 0.24 x OD 30mm |
| 6. | HG23H12012G1 | [1] | HYD CONNECTOR | KOB(Incls. O-Ring ZD12P02400) |
| 6-1. | ZD12P02400 | [1] | O-RING | KOBID 23.70 ± 0.24 x OD 30mm |
| 7. | YB03H01050P1 | [1] | BLOCK | KOBBLOCK |
| 9. | ZD12P03400 | [2] | O-RING,0.139" Thk x 1.296" ID, -219, Cl 6, 90 Duro | KOBID 33.70 ± 0.33 x OD 40mm |
| 10. | ZE13X16000 | [2] | FLANGE | KOBClamp, Half -- (Incls. Capscrew & Lockwasher) |
| 11. | 2444Z3203 | [1] | ELBOW | KOB Superseded by part number: HH35X16016G1 |
| 11-1. | ZD12P02900 | [1] | O-RING | KOBID 28.70 ± 0.29 x OD 35mm |
| 12. | YB03H01047P1 | [1] | U-BRACKET | KOBBRACKET Superseded by part number: YB03H01060P1 |
| 13. | YB03H01025P1 | [1] | SUPPORT | KOBSUPPORT |
| 14. | YB03H01046P1 | [1] | CLAMP | KOBCLAMP |
| 15. | ZS18C10030 | [4] | SCREW,Hex, M10 x 30mm | KOBM10x1.50x30mm |
| 16. | ZS18C12030 | [5] | SCREW,Hex, M12 x 30mm | KOBM12x1.75x30mm |
| 17. | ZS18C12085 | [2] | SCREW,Hex, M12 x 85mm | KOBM12x1.75x85mm |
| 18. | ZW16H10000 | [4] | WASHER | KOBID 11 x OD 24 x Th 3.2mm |
| 19. | ZW16H12000 | [9] | WASHER | KOBID 13 x OD 26 x Th 3.2mm |
| 20. | ZN18C12010 | [2] | NUT | KOBM12x1.75mm |
| 21. | ZD12A01800 | [1] | O-RING,1.78mm Thk x 18.77mm ID, Cl 6 | KOBID 18.77 ± 0.12 x OD 22.33mm |
| 22. | ZD12A02100 | [2] | O-RING | KOBID 23.52 ± 0.15 x OD 27.08mm |
| 23. | ZS28C12070 | [4] | CAPSCREW,Hex Socket Head, M12 x 70mm | KOBSCREW M12x1.75x70mm |
| 24. | ZS28C12040 | [4] | SCREW,Hex Socket Head, M12 x 40mm | KOBM12x1.75x40mm |
| 25. | ZW26K12000 | [8] | LOCK WASHER | KOBID 12 x OD 17.8 x Th 2.5mm |
