纽荷兰零件查询(E235BSRNLC) - CRAWLER EXCAVATOR ASN YU05-02001 (06-006[04]) - CAB GUARD New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
420 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YB01C00003F1 | [1] | GUARD | KOB |
| . . | YN02C03461F1 | [1] | GUARD | KOBAssy. Incl. A1-A2 |
| A1. | YN02C03343P1 | [1] | GUARD | KOB |
| A2. | ZM73C12030 | [4] | BOLT,M12x30mm - Course Thread | KOB |
| . . | YN02C03462F1 | [1] | GUARD | KOBAssy. Incl. B1-B13 |
| B1. | YN21C00122F1 | [1] | GUARD | KOB |
| B1-1. | YN02C03383P1 | [1] | GUARD | SM |
| B1-2. | YN20T01378P2 | [1] | NUMBER PLATE LAMP | KOB |
| B1-3. | 4020Z64 | [4] | RIVET | KOB Superseded by part number: 2420P623D7 |
| B2. | ZN18C10008 | [4] | NUT | KOB |
| B3. | ZW16H10000 | [4] | WASHER | KOB |
| B4. | YN02C03597P1 | [1] | ROD | KOB |
| B5. | YN21C01178P1 | [1] | CLIP | KOB |
| B6. | ZM66C04012 | [1] | BOLT | KOB |
| B7. | ZN16C04003 | [1] | NUT | KOB Superseded by part number: ZN18C04003 |
| B8. | ZW16P04000 | [1] | WASHER | KOB |
| B9. | HY25X10027G1 | [1] | WASHER,10mm ID x 27mm OD x 3.2mm Thk | KOB |
| B10. | 2419R9D2 | [1] | COTTER PIN | KOB |
| B12. | YN02C03199P1 | [2] | NUT | KOB |
| B13. | YN02C03660P1 | [2] | SHIM,32mm OD x 1.6mm Thk | KOB |
