| . . | YB06H00005F2 | [1] | | |
| 1. | ZH22X04000 | [3] | HYD CONNECTOR,1/4" NPT x 1/4" NPT | KOB1/4"PFx36mm Long (Incls. O-Ring ZD12P01100) |
| 2. | ZH22X04006 | [7] | HYD CONNECTOR | KOB(Incls. O-Ring 237-6006) |
| 3. | ZH22X06000 | [9] | HYD CONNECTOR | KOB(Incls. O-Ring ZD12P01400) |
| 4. | 2444Z2525 | [1] | HYD CONNECTOR | KOB1/4"PFx35mm Long (Incls. O-Ring ZD12P01100) Superseded by part number: 72217408 |
| 5. | 2444T2505 | [4] | HYD CONNECTOR | KOB1/4" PF - 3/8" PF x 35mm Long (Incls. O-Ring ZD12P01400) |
| 6. | 2444Z3711 | [2] | HYD CONNECTOR | KOB(Incls. O-Ring ZD12P01400) |
| 7. | YN21V00005F2 | [1] | CHECK VALVE | KOBCheck, (Incls. O-Ring ZD12P01400) |
| 9. | 2444R1120D065 | [1] | HOSE | KOB650mm Long (25-1/2 in) |
| 10. | YN06H01017P1 | [2] | HYD CONNECTOR | KOB3/8" PF - 3/8" PF x 35mm Long (Incls. O-Rings ZD12P01400) |
| 11. | ZH32X04000 | [5] | 90 ELBOW,Male, 30 Degree Fl, PF 1/4" x PF 1/4", O-Ring | KOBElbow, 90° -- PF 1/4, (Incls. O-Ring 237-6004) |
| 12. | ZH32X04006 | [7] | 90 ELBOW,Male, 30 Degree Fl, PF 1/4" x PF 3/8", O-Ring | KOB90° -- 1/4"x3/8"PF (Incls. O-Ring 237-6006 Alternate ZD12P01400) |
| 13. | ZH32X06000 | [2] | 90 ELBOW,Male, 30 Degree Fl, PF 3/8" x PF 3/8", O-Ring | KOBElbow, 90° -- (Incls. O-Ring ZD12P01400) Alternate O-Ring 237-6006 |
| 14. | 2444Z3155 | [4] | 90 ELBOW,PF 3/8" Fem x PF 3/8" Male | KOB90° -- (PF 3/8) (Incls. O-Ring ZD12P01400) Alternate O-Ring 237-6006 Superseded by part number: YT42H01128P1 |
| 15. | HH55Q04004G1 | [3] | TEE,1/4" ORB x 1/4" JIC x 1/4" JIC | KOB1/4" PF (Incls. O-Ring ZD12P01100) |
| 16. | HH55Q06006G1 | [8] | TEE | KOB3/8" PF (Incls. O-Ring ZD12P01400) |
| 17. | 2444Z2336 | [1] | TEE | KOBTee -- 1/4"x3/8"x3/8"PF (Incls. O-Ring ZD12P01100) |
| 18. | 2444Z2457 | [1] | TEE | KOB |
| 19. | YX52S00005P1 | [5] | PRESSURE SWITCH | KOB Superseded by part number: YX52S00012F1 |
| 19-1. | ZD12P01100 | [1] | O-RING | KOBID 10.8mm x OD 13.2mm |
| 20. | ZX23M04030 | [1] | FLEXIBLE HOSE | KOB |
| 21. | ZX23M04076 | [1] | HOSE | KOB760mm Long (29-59/64 in) |
| 22. | 2444R1120D030 | [2] | HOSE | KOB300mm Long (11-13/16 in) |
| 23. | 2444R1120D060 | [2] | HOSE | KOB600mm Long (23-5/8 in) |
| 24. | ZX23M04070 | [1] | HOSE ASSY. | KOB700mm Long (27-1/2 in) |
| 25. | ZX23M04066 | [1] | FLEXIBLE HOSE | KOB660mm Long (25-63/64 in) Superseded by part number: ZX23M04070 |
| 26. | 2444R596D1 | [1] | 90 ELBOW | KOB90° -- 1/4" PF |
| 27. | 2414Z199D60 | [4] | PROTECTIVE SLEEVE | KOBHOSE |
| 28. | ZE72X06000 | [1] | PLUG | KOB3/8" PF, (Incls. O-Ring ZD12P01400) |
