纽荷兰零件查询(E235BSRNLC) - CRAWLER EXCAVATOR ASN YU05-02001 (02-006) - IDLER ASSY, CRAWLER, P/N LQ52D00025F1 New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
695 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | LQ52D00025F1 | [1] | IDLER | KOBASSY, CRAWLER |
| 1. | YN52D00009F1 | [1] | IDLER | KOBASSY, SEE FIG. 02-007 Superseded by part number: LQ52D00044F1 |
| 2. | LQ54D00010F1 | [1] | SPRING | SMADJUST ASSY, SEE FIG. 02-008 Superseded by part number: LQ54D00010F8 |
| 3. | ZS13C16045 | [2] | SCREW | KOBSCREW |
| 4. | 2444P803 | [1] | LUBE NIPPLE,5/8” – 18 x 64mm L, 19mm Hex | KOBGREASE |
