现代零件查询R250LC-7A TRAVEL MOTOR(2/2, TYPE 2)EPC Hyundai
广数供应链运营团队, 15 02月, 2025，浏览：
798 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| . |
@
|
[1] |
TRAVEL MOTOR ASSY
|
|
| . |
@
|
[1] |
TRAVEL MOTOR
|
|
| 1. |
XKAY-01090
|
[1] |
CASING-SHAFT
|
|
| 2. |
XKAY-00443
|
[10] |
PLUG
|
|
| N3. |
XKAY-00444
|
[1] |
SEAL-OIL
|
|
| -11. |
XKAY-00518
|
[1] |
SEAL KIT
|
|
| N4. |
XKAY-00446
|
[2] |
PISTON-SWASH
|
|
| N5. |
XKAY-00447
|
[2] |
RING-PISTON
|
|
| 6. |
XKAY-00448
|
[1] |
SHAFT
|
|
| 7. |
XKAY-00449
|
[1] |
BEARING
|
|
| 8. |
XKAY-00450
|
[2] |
BALL-STEEL
|
|
| 9. |
XKAY-01931
|
[1] |
PLATE-SWASH
|
|
| -12. |
XKAY-00963
|
[1] |
ROTARY KIT
|
|
| -121. |
XKAY-00453
|
[1] |
KIT-CYLINDER BLOCK
|
|
| N10. |
XKAY-01093
|
[1] |
BLOCK-CYLINDER
|
|
| 11. |
XKAY-00455
|
[1] |
SEAT-SPRING
|
|
| 12. |
XKAY-00456
|
[1] |
SPRING
|
|
| 13. |
XKAY-00457
|
[1] |
PLATE-END
|
|
| 14. |
XKAY-00458
|
[1] |
RING-SNAP
|
|
| 15. |
XKAY-00459
|
[3] |
PIN
|
|
| 70. |
XKAY-01095
|
[1] |
PLATE-VALVE
|
|
| -122. |
XKAY-00460
|
[1] |
RETAINER KIT
|
|
| 16. |
XKAY-00461
|
[1] |
BALLGUIDE
|
|
| 17. |
XKAY-00462
|
[1] |
PLATE-SET
|
|
| -123. |
XKAY-00463
|
[1] |
PISTON KIT
|
|
| 18. |
XKAY-01899
|
[9] |
PISTON ASSY
|
|
| 19. |
XKAY-00465
|
[3] |
PLATE-FRICTION
|
|
| 20. |
XKAY-00466
|
[3] |
PLATE
|
|
| 21. |
XKAY-00467
|
[1] |
PISTON-PARKING
|
|
| 22. |
XKAY-01395
|
[1] |
O-RING
|
|
| 23. |
XKAY-00469
|
[1] |
RING-BACK UP
|
|
| 24. |
XKAY-01404
|
[1] |
O-RING
|
|
| 25. |
XKAY-00471
|
[1] |
RING-BACK UP
|
|
| 26. |
XKAY-00472
|
[1] |
ORIFICE
|
|
| 27. |
XKAY-01405
|
[3] |
O-RING
|
|
| 28. |
XKAY-01406
|
[1] |
O-RING
|
|
| 69. |
XKAY-00513
|
[1] |
BEARING
|
|
