纽荷兰零件查询(E235BSRNLC) - CRAWLER EXCAVATOR ASN YU05-02001 (01-019[02]) - HYD LINES, PUMP (SUCTION, DELIVERY) New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
843 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YF30H00007F1 | [1] | HYD LINES, PUMP | |
| . . | YF30H00009F1 | [1] | HYD LINES, PUMP | |
| A1. | YF30H01040D1 | [1] | HOSE | KOB |
| A2. | YF30H01041D1 | [1] | HOSE | KOB |
| A3. | YF30H01006P1 | [1] | HOSE | KOB |
| A4. | YF30H01038P1 | [2] | RUBBER BAND | KOB Superseded by part number: YF30H01057P1 |
| A5. | YF30H01039P1 | [2] | RUBBER BAND | KOB Superseded by part number: YF30H01058P1 |
| A6. | YF30H01025P1 | [2] | PLATE | KOB |
| A7. | YF30H01023P1 | [1] | GROMMET | KOB |
| A8. | ZH32X12000 | [1] | 90 ELBOW,Male, 30° Fl, PF 3/4" x PF 3/4", O-Ring | KOB |
| A9. | ZE72X04000 | [2] | PLUG | KOB |
| A10. | ZE13X16000 | [8] | FLANGE | KOBCLAMP, HALF |
| A11. | HM83C12040G1 | [16] | BOLT | KOBSEMS |
| A12. | ZS18C12090 | [2] | SCREW,Hex, M12 x 90mm | KOBCAP |
| A13. | ZW16H12000 | [2] | WASHER | KOB |
| A14. | ZY26X06060 | [2] | SPACER | KOB |
| A15. | PY01P01043D8 | [1] | CABLE TIE,102mm L | KOB |
| A16. | ZC16X09100 | [2] | CLIP | KOB |
| A17. | ZC16X10000 | [2] | CLIP | KOB |
| A18. | ZD12P03400 | [4] | O-RING,0.139" Thk x 1.296" ID, -219, Cl 6, 90 Duro | KOB |
| A19. | YN52S00048P1 | [2] | SENSOR | SMPressure (High Pressure) (Incls. O-Ring ZD12P01400) Superseded by part number: LS52S00015P1 |
| . . | ZD12P01400 | [1] | O-RING | KOB(Part of YN52S00048P1), ID 13.80 ± 0.19 x OD 18mm, Not Shown |
| A20. | YF30H01035D1 | [2] | HOSE | KOB |
| A21. | ZD12A02100 | [2] | O-RING | KOB |
| . . | YF30H00005F1 | [1] | HYD LINES, PUMP | |
| B1. | YF30H01014P1 | [1] | ELBOW | KOB |
| B2. | ZS28C12030 | [4] | SCREW,Hex Socket Head, M12 x 30mm | KOBSCREW |
| B3. | ZW26K12000 | [4] | LOCK WASHER | KOB |
| B4. | 45Z91D104 | [1] | O-RING,3.53mm Thk x 69.44mm ID, 80 Duro | KOB Superseded by part number: 923582 |
