纽荷兰零件查询(E235BSRNLC) - CRAWLER EXCAVATOR ASN YU05-02001 (01-021) - HYD LINES, UPP (BOOM & ARM SAFETY) New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
938 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YF03H00081F1 | [1] | HYD LINES, UPP | |
| . . | YF03H00037F1 | [1] | HYD LINES, UPP, SEE FIG. 01-020-01 TO 01-020-04 | |
| . . | YF03H00039F1 | [1] | HYD LINES, UPP, SEE FIG. 01-020-01 TO 01-020-04 | |
| . . | YF03H00022F1 | [1] | HYD LINES, UPP, SEE FIG. 01-020-01 TO 01-020-04 | |
| . . | YF03H00059F1 | [1] | HYD LINES, UPP, SEE FIG. 01-020-01 TO 01-020-04 | |
| . . | YF03H00040F1 | [1] | HYD LINES, UPP, SEE FIG. 01-020-01 TO 01-020-04 | |
| . . | YF03H00070F1 | [1] | HYD LINES, UPP, SEE FIG. 01-020-01 TO 01-020-04 | |
| . . | YF03H00071F1 | [1] | HYD LINES, UPP, SEE FIG. 01-020-01 TO 01-020-04 | |
| . . | YF03H00042F1 | [1] | HYD LINES, UPP | |
| A1. | YF03H01217P1 | [1] | PLATE | KOBPLATE |
| A2. | YF03H01258P1 | [1] | RUBBER BAND | KOBRUBBER |
| A3. | ZS18C08045 | [2] | SCREW,Hex, M8 x 45mm | KOBCAP |
| A4. | ZW16H08000 | [2] | WASHER | KOBID 08 x OD 18 x Th 3.2mm |
| A5. | ZY26X04028 | [2] | SPACER | KOBSPACER |
| . . | YF03H00045F1 | [1] | HYD LINES, UPP | |
| B1. | YF03H01221P1 | [1] | CAP | KOBCAP |
| . . | YF03H00041F1 | [1] | HYD LINES, UPP | |
