纽荷兰零件查询(E235BSRNLC) - CRAWLER EXCAVATOR ASN YU05-02001 (01-054[02]) - GUARD INSTAL, P/N YF22C01327F1 New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
865 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YF22C01327F1 | [1] | DUCT | KOBASSY |
| A1. | YF22C01318P2 | [1] | DUCT | KOBDUCT |
| A2. | YF22C01279P1 | [1] | FOAM INSULATION | KOB |
| A3. | YF22C01280P1 | [1] | FOAM INSULATION | KOB |
| A4. | YF22C01281P1 | [5] | FOAM INSULATION | KOB |
| A5. | YF22C01282P1 | [1] | FOAM INSULATION | KOB |
| A6. | YF22C01283P1 | [1] | FOAM INSULATION | KOB |
| A7. | YF22C01284P1 | [1] | FOAM INSULATION | KOB |
| A8. | YF22C01285P1 | [1] | FOAM INSULATION | KOB |
| A9. | YF22C01286P1 | [1] | FOAM INSULATION | KOB |
| A10. | YF22C01287P1 | [1] | FOAM INSULATION | KOB |
| A11. | YF22C01330P1 | [1] | FOAM INSULATION | KOB |
| . . | YF22C01262F1 | [1] | HOOD | KOBBONNET ASSY |
| B1. | YF22C01232P2 | [1] | HOOD | KOBBONNET |
| B2. | YF22C01278P1 | [1] | FOAM INSULATION | KOB |
| B3. | YJ21C01103D4 | [1] | INSULATING PANEL | KOBSTRIP, WEATHER |
| B4. | YR21C01168D9 | [1] | RUBBER SEAL | KOBSTRIP, WEATHER |
| B5. | YT21C01159D6 | [1] | WEATHERSTRIP | KOB |
| B6. | YY22P01010D3 | [1] | TRIM PANEL | KOB |
| . . | YF22C00014F1 | [1] | HOOD | KOBBONNET ASSY |
| C1. | YF22C01414P2 | [1] | HOOD | KOBBONNET Superseded by part number: YF22C01414P3 |
| C1-7. | YF22C01258P1 | [2] | HINGE | KOB |
| C1-8. | YN21C02202P1 | [1] | LOCK | SM Superseded by part number: YN21C03803P1 |
| C2. | YF22C01371P1 | [1] | HOOD | KOB |
| C3. | YF22C01372P1 | [1] | FOAM INSULATION | KOB |
| C4. | YF22C01373P1 | [1] | FOAM INSULATION | KOB |
| C5. | YF22C01374P1 | [1] | FOAM INSULATION | KOB Superseded by part number: YF22C01438P1 |
| C6. | YF22C01405P1 | [1] | FOAM INSULATION | KOBINSULATION |
| C7. | YF22C01406P1 | [1] | FOAM INSULATION | KOBINSULATION |
| C8. | PH22C01101D4 | [1] | RUBBER BAND | KOB |
| C9. | PM22C01013D6 | [2] | WEATHERSTRIP | KOB |
| C10. | YN21C01712DL | [1] | WEATHERSTRIP | KOB |
| C11. | PH21C01021D7 | [1] | WEATHERSTRIP | KOB |
| C12. | ZM73C08020 | [4] | BOLT,M8x20mm - Course Thread | KOBM08x1.25x20mm (Incls. Washer) |
| C13. | PH05P01084D4 | [1] | RUBBER PAD | KOBRUBBER, Start Serial: YU05-02058 |
| . . | YF22C01338F1 | [1] | DUCT | KOBASSY |
| D1. | YF22C01417P2 | [1] | DUCT | KOBDUCT |
| D2. | YF22C01355P1 | [1] | FOAM INSULATION | KOB |
| D3. | YF22C01356P1 | [1] | FOAM INSULATION | KOB |
| D4. | YF22C01304P1 | [1] | FOAM INSULATION | KOB |
| D5. | YF22C01431P1 | [1] | FOAM INSULATION | KOBINSULATION |
| D6. | YF22C01359P1 | [1] | FOAM INSULATION | KOB |
| D7. | YF22C01358P1 | [1] | FOAM INSULATION | KOB |
| D8. | YF22C01369P1 | [1] | FOAM INSULATION | KOB |
| D9. | YF22C01360P1 | [1] | FOAM INSULATION | KOB |
| D10. | YF22C01361P1 | [1] | FOAM INSULATION | KOB |
| D11. | YF22C01362P1 | [1] | FOAM INSULATION | KOB |
| D12. | YF22C01364P1 | [1] | FOAM INSULATION | KOB |
| D13. | YF22C01365P1 | [1] | FOAM INSULATION | KOB |
| D14. | YF22C01366P1 | [1] | FOAM INSULATION | KOB |
| D16. | PH03M01305D4 | [1] | RUBBER BAND | KOBRUBBER |
| D17. | PF02C01062D4 | [1] | RUBBER BAND | KOB |
| D18. | PF02C01062D5 | [1] | RUBBER BAND | KOB |
| D19. | PM21C01136D6 | [1] | WEATHERSTRIP | KOB |
| D20. | YR21C01168DD | [1] | WEATHERSTRIP | KOBSTRIP, WEATHER |
| D21. | YR21C01168DN | [1] | WEATHERSTRIP | KOB |
| D22. | YR21C01165DA | [1] | WEATHERSTRIP | KOB |
| D23. | YR21C01168DC | [2] | WEATHERSTRIP | KOB |
| D24. | YJ21C01154D4 | [1] | RUBBER | KOB |
| . . | YF22C01403F1 | [1] | DUCT | KOBDUCT ASSY Superseded by part number: YB22C01067F1 |
| E1. | YF22C01402P1 | [1] | DUCT | KOB |
| E2. | YF22C01413P1 | [1] | INSULATOR | KOB |
