久保田零件查询H10600 TILT LEVER STEERINGEPC Kubota online
广数供应链运营团队, 15 02月, 2025，浏览：
739 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 010. |
6C17041390
|
[2] |
PIN STEERING POST
|
0.1760(lbs); 0.080
|
| 020. |
0112360814
|
[2] |
BOLT
|
0.0220(lbs); 0.010
|
| 030. |
6C17041455
|
[1] |
LEVER CLAMP
|
0.2640(lbs); 0.120
|
| 040. |
6C17041460
|
[1] |
LINK CLAMP LEVER
|
0.0440(lbs); 0.020
|
| 050. |
6C17041472
|
[1] |
LEVER TILT HANDLE
|
0.1540(lbs); 0.070
|
| 060. |
0512250818
|
[1] |
PIN JOINT
|
0.0176(lbs); 0.008
|
| 070. |
0401250080
|
[2] |
WASHER PLAIN
|
0.0022(lbs); 0.001
|
| 080. |
0551150215
|
[2] |
PIN SPLIT
|
0.0022(lbs); 0.001
|
| 090. |
4152275680
|
[1] |
SPRING
|
0.0220(lbs); 0.010
|
| 100. |
6C17041480
|
[1] |
STAY CLAMP LEVER
|
0.3630(lbs); 0.165
|
| 110. |
0112360816
|
[3] |
BOLT
|
0.0220(lbs); 0.010
|
| 120. |
6C04041360
|
[1] |
GRIP LEVER
|
0.0264(lbs); 0.012
|
