纽荷兰零件查询(E235BSRNLC) - CRAWLER EXCAVATOR ASN YU05-02001 (01-059) - CONTROLLER INSTAL New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
575 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YF22E00038F1 | [1] | CONTROLLER INSTAL | |
| . . | YB22E00021F1 | [1] | CONTROLLER INSTAL | |
| A1. | YB22E01027P1 | [1] | SUPPORT | KOBSUPPORT Superseded by part number: YB22E01027P3 |
| A3. | YN50S00047P1 | [1] | TOGGLE SWITCH | KOB |
| A4. | YN22M01014P1 | [1] | LABEL | KOB |
| A7. | ZM73C08020 | [5] | BOLT,M8x20mm - Course Thread | KOBM08x1.25x20mm (Incls. Washer) |
| A9. | ZM61C06025 | [7] | BOLT | KOBSEMS |
| A10. | ZM41C03008 | [4] | BOLT | KOBSEMS |
| A11. | ZM61C04012 | [1] | BOLT | KOBSEMS |
| A12. | YX50S00001F1 | [1] | TOGGLE SWITCH | SMASSY |
| A13. | YV22E01002P1 | [1] | LABEL | KOB |
| A14. | LC22E01001D1 | [1] | RESISTOR,16ohm | KOB |
| . . | YB22E00022F1 | [1] | CONTROLLER INSTAL | |
| B3. | YB22E01012P1 | [1] | BRACKET | KOB |
| B4. | YB22E01013P1 | [1] | BRACKET | KOB |
| B5. | ZM61C05012 | [4] | BOLT | KOBSEMS |
| B6. | ZM61C06016 | [5] | BOLT | KOBSEMS |
| B1. | NSS | [1] | NOT SERVICED SEPARATELY | CONCONTROLLER, HINO PARTS NO "Engine Parts" |
| . . | YF22E00035F1 | [1] | CONTROLLER | KOBAssembly incl. ref. C1,C2,C3, Serial Range: YU05-02001-YU05-02041 Superseded by part number: YF22E00035F3 |
| . . | YF22E00035F2 | [1] | Assembly incl. ref. C1,C2,C3, Start Serial: YU05-02042 | |
| C1. | YN22E00214F1 | [1] | CONTROL | KOBNo Software installed Superseded by part number: YN22E00425F1 |
| . . | YN22E00425F1R | [1] | REMAN-ELECTRONIC CONTROL UNIT | KOBE235BSRLC, E235BSRNLC, BOTH ASN YU05-02001, E235BSR ASN YF05-02001 Reman For New P/N YN22E00214F1 |
| . . | YN22E00425F1C | [1] | CORE-ELECTRONIC CONTROL UNIT | KOBReturn Number |
| C2. | NS | [1] | NOT SERVICED | BAS, Serial Range: YU05-02001-YU05-02041 |
| . . | YN24E00019F1 | [1] | RELAY | KOBBOX ASSY |
| D1. | YN24E00016F1 | [1] | RELAY | KOBBOX ASSY, SEE FIG. 01-060 Superseded by part number: YN24E00016F3 |
| D2. | YN73E01023P2 | [1] | LABEL | KOBLABEL |
| . . | YB77S00001F1 | [1] | CONVERTER ASSY | |
| E1. | YT77S00001P1 | [1] | CONVERTER,24V In - 12V Out - 2.5A | KOB Superseded by part number: YT77S00011P1 |
