现代零件查询R28-7 HOOD & COVEREPC Hyundai
广数供应链运营团队, 15 02月, 2025，浏览：
437 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
XJDH-01803
|
[1] |
COVER-BATTERY
|
|
| 2. |
XJDH-00035
|
[4] |
BOLT
|
|
| 3. |
XJDH-00276
|
[4] |
WASHER
|
|
| 4. |
XJDH-00805
|
[2] |
PLUG-RUBBER CUSHION
|
|
| 5. |
XJDH-01008
|
[1] |
HANDLE
|
|
| 6. |
XJDH-02845
|
[2] |
KEY ASSY
|
|
| 7. |
XJDH-02846
|
[1] |
ROCK PLATE-KEY
|
|
| 8. |
XJDH-01457
|
[1] |
PLATE
|
|
| 9. |
XJDH-00035
|
[6] |
BOLT
|
|
| 10. |
XJDH-00276
|
[6] |
WASHER
|
|
| 11. |
XJDH-01797
|
[1] |
HOOD
|
|
| 12. |
XJDH-01147
|
[2] |
HINGE
|
|
| 13. |
XJDH-00034
|
[4] |
BOLT
|
|
| 14. |
XJDH-00276
|
[4] |
WASHER
|
|
| 15. |
XJDH-01789
|
[1] |
LOCK ASSY
|
|
| 16. |
XJDH-00021
|
[4] |
BOLT
|
|
| 17. |
XJDH-00274
|
[4] |
WASHER
|
|
| 18. |
XJDH-01811
|
[1] |
BRACKET
|
|
| 19. |
XJDH-00021
|
[2] |
BOLT
|
|
| 20. |
XJDH-00274
|
[2] |
WASHER
|
|
| 21. |
XJDH-01788
|
[1] |
STRIKER
|
|
| 22. |
XJDH-00037
|
[2] |
BOLT
|
|
| 23. |
XJDH-00276
|
[2] |
WASHER
|
|
| 24. |
XJDH-01466
|
[1] |
BRACKET ASSY
|
|
| 25. |
XJDH-00058
|
[2] |
BOLT
|
|
| 26. |
XJDH-00278
|
[2] |
WASHER
|
|
| 27. |
XJDH-01406
|
[AR] |
SHIM(2.3T)
|
|
| 28. |
XJDH-01407
|
[AR] |
SHIM(1.2T)
|
|
| 29. |
XJDH-01810
|
[1] |
PLATE
|
|
| 30. |
XJDH-01804
|
[1] |
FORM-URETHAN
|
|
| 31. |
XJDH-01465
|
[1] |
FORM-URETHAN(B)
|
|
| 32. |
XJDH-01793
|
[1] |
COVER
|
|
| 33. |
XJDH-00021
|
[4] |
BOLT
|
|
| 34. |
XJDH-00274
|
[4] |
WASHER
|
|
| 35. |
XJDH-01464
|
[1] |
COVER(R)
|
|
| 36. |
XJDH-00021
|
[4] |
BOLT
|
|
| 37. |
XJDH-00274
|
[4] |
WASHER
|
|
| 38. |
XJDH-00764
|
[1] |
TRIM
|
|
| 39. |
XJDH-00710
|
[1] |
STRIP-WEATHER
|
|
| 40. |
XJDH-01381
|
[1] |
WIRE ROPE
|
|
| 41. |
XJDH-00030
|
[2] |
BOLT
|
|
| 42. |
XJDH-00276
|
[2] |
WASHER
|
|
| 43. |
XJDH-01461
|
[1] |
FORM-URETHAN
|
|
