沃尔沃零件查询TAMD63L-A; TAMD63P-AEngineTiming Gear HousingEPC Volvo Penta Parts catalog
广数供应链运营团队, 15 02月, 2025，浏览：
848 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
471505
|
[1] |
Timing gear casing
|
|
| 2. |
941511
|
[1] |
Pin
|
|
| 3. |
941510
|
[1] |
Pin
|
|
| 4. |
1161231
|
[1] |
Sealant
|
304ml
|
| 4. |
1161277
|
[1] |
Sealant
|
20g
|
| 5. |
471534
|
[2] |
Flange screw
|
L=28mm
|
| 5. |
471535
|
[2] |
Flange screw
|
L=58mm
|
| 6. |
422766
|
[1] |
Bearing spindle
|
|
| 7. |
8192518
|
[1] |
Gear
|
(471552)
|
| 8. |
478951
|
[1] |
Thrust washer
|
|
| 9. |
471554
|
[3] |
Flange screw
|
|
| 10. |
8192590
|
[1] |
Cover
|
|
| 11. |
477118
|
[1] |
Sealing ring
|
|
| 12. |
965182
|
[6] |
Flange screw
|
M8x80mm
|
| 12. |
965216
|
[1] |
Flange screw
|
M8x55mm
|
| 12. |
948217
|
[2] |
Flange screw
|
M8x45mm
|
| 12. |
947760
|
[7] |
Flange screw
|
M8x40mm
|
| 12. |
965183
|
[1] |
Flange screw
|
M8x90mm
|
| 12. |
965192
|
[1] |
Flange screw
|
M12x40mm
|
| 13. |
947281
|
[1] |
Gasket
|
|
| 14. |
946471
|
[1] |
Flange screw
|
|
| 15. |
955895
|
[2] |
Washer
|
|
| 16. |
100338
|
[2] |
Hexagon screw
|
M10x95mm
|
| 17. |
479971
|
[1] |
Stud
|
M10x45mm
|
| 18. |
925094
|
[1] |
O-ring
|
|
| 19. |
465735
|
[1] |
Cover
|
|
| 20. |
479972
|
[1] |
Stud
|
M10x45mm
|
| 21. |
971095
|
[1] |
Flange nut
|
|
| 22. |
965188
|
[1] |
Flange screw
|
|
| 23. |
925094
|
[1] |
O-ring
|
|
| 24. |
471559
|
[1] |
Cover
|
|
| 25. |
941907
|
[3] |
Spring washer
|
|
| 26. |
945444
|
[3] |
Flange screw
|
|
| 27. |
925095
|
[1] |
O-ring
|
|
| 28. |
|
|
|
|
| 29. |
965187
|
[1] |
Flange screw
|
M10x60mm
|
| 29. |
965190
|
[2] |
Flange screw
|
M10x100mm
|
| 30. |
969313
|
[1] |
Flange screw
|
M10x110mm
|
| 31. |
971098
|
[3] |
Flange lock nut
|
|
| 32. |
|
|
|
See group 30
|
| 33. |
420178
|
[1] |
Cover
|
|
| 34. |
967951
|
[3] |
Stud
|
|
| 35. |
971097
|
[3] |
Flange nut
|
|
| 35A. |
955899
|
[3] |
Washer
|
D=15x26x2mm
|
| 36. |
975610
|
[1] |
O-ring
|
|
