现代零件查询R28-7 BUCKET LINKAGEEPC Hyundai
广数供应链运营团队, 15 02月, 2025，浏览：
393 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
XJDH-01134
|
[1] |
LINK ASSY(LH)-BUCKET
|
|
| 2. |
XJDH-01135
|
[1] |
LINK ASSY(RH)-BUCKET
|
|
| 3. |
XJDH-01136
|
[1] |
LINK ASSY-DUMP
|
|
| 301. |
XJDH-01041
|
[2] |
BUSHING
|
|
| 302. |
XJDH-01059
|
[2] |
BUSHING
|
|
| 4. |
XJDH-00377
|
[2] |
NIPPLE-GREASE 90
|
|
| 5. |
XJDH-01042
|
[1] |
PIN-BUCKET CYL ROD
|
|
| 6. |
XJDH-01043
|
[1] |
PIN-BUCKET LINK
|
|
| 7. |
XJDH-00373
|
[2] |
NIPPLE-GREASE
|
|
| 8. |
XJDH-00064
|
[2] |
BOLT
|
|
| 9. |
XJDH-00175
|
[4] |
NUT
|
|
| 10. |
XJDH-01192
|
[AR] |
SHIM(A, 0.5T)
|
|
| 11. |
XJDH-01193
|
[AR] |
SHIM(B, 1.0T)
|
|
