凯斯零件查询(LB324S) - BALER (9/12-) (55.404.030) - WORK LIGHT Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
544 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
84386750
|
[1] |
WIRE HARNESS
|
ZED
|
| 2. |
84423707
|
[4] |
WORK LAMP
|
ZED
Incl 12
|
| 3. |
86566990
|
[7] |
CABLE TIE,292mm OAL x 4.8mm W
|
ZED
|
| 4. |
9837606
|
[1] |
CLIP
|
ZED
Superseded by part number: 847590
|
| 5. |
86507486
|
[2] |
CARRIAGE BOLT,M8 x 1.25 x 20mm, Cl 8.8
|
NH
|
| 6. |
322358
|
[2] |
BELLEVILLE WASHER,M8 Bolt Size x 18mm OD x 1.4mm Thk
|
NH
|
| 7. |
9706690
|
[2] |
NUT,M8 x 1.25, Cl 8
|
NH
Superseded by part number: 43362
|
| 8. |
9813909
|
[1] |
SUPPORT
|
ZED
|
| 9. |
84790023
|
[1] |
WORK LAMP
|
ZED
, Serial Range: -C089
|
| 9. |
84790030
|
[1] |
WORK LAMP
|
ZED
Incl 13, Start Serial: D090 Superseded by part number: 86508819, 87705140, 84790023, 430026, 264517
|
| 10. |
853765
|
[2] |
CLAMP,7.9mm, Coat, 10.3mm Bolt Hole, P Type
|
NH
|
| 11. |
81844483
|
[2] |
PLUG,.73" x 1"
|
A
Superseded by part number: 81819333
|
| 12. |
84423773
|
[1] |
BULB,Halogen, 12V, 27W
|
ZED
|
| 13. |
417720
|
[1] |
BULB,12V, 55W
|
ZED
, Start Serial: D090 Superseded by part number:
|
