纽荷兰零件查询(E235BSRNLC) - CRAWLER EXCAVATOR ASN YU05-02001 (01-071[04]) - HARNESS ASSY, UPP, P/N YB13E00023F1 New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
374 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YB13E00023F1 | [1] | HARNESS ASSY, UPP | |
| A1. | YB13E01070P2 | [1] | HARNESS | KOBHARNESS Superseded by part number: |
| A2. | YB13E01040P2 | [1] | CABLE | KOBCABLE |
| A3. | YB13E01039P1 | [1] | CABLE | KOBCABLE |
| A4. | YB13E01038P1 | [1] | CABLE | KOBCABLE |
| A5. | YB13E01060P1 | [1] | CABLE | KOBCABLE |
| A6. | YB13E01059P2 | [1] | HARNESS | KOB |
| A7. | LQ13E01100P1 | [1] | CABLE | KOB |
| A8. | LE13E01006P1 | [1] | HARNESS | KOBCABLE |
| A9. | ZM73C10016 | [1] | BOLT,M10x16mm - Course Thread | KOBSEMS |
| A11. | YN13E01375P1 | [28] | CLIP,M8 x 8.20mm Shank | KOB |
| A12. | PY01P01043D3 | [82] | CABLE TIE,188mm L | KOBWire Ties -- 188mm Long |
| A13. | EW02E01015D4 | [2] | CLIP | KOB |
| A14. | EW02E01015D6 | [3] | CLIP | KOB |
| A15. | EW02E01015DC | [1] | CLIP | KOB |
| A16. | EW02E01015D9 | [2] | CLIP,20mm ID, P Type | KOB |
| A17. | EW02E01015DA | [1] | CLIP | KOB |
| A18. | PY01P01043D8 | [5] | CABLE TIE,102mm L | KOB |
| A19. | YB13E01061P1 | [1] | PLATE | KOB |
| A20. | ZC48X24014 | [7] | CLIP | KOBClamp, Double -- Ø24x85mm Long |
| A21. | ZC46X50014 | [1] | CLIP | KOB |
| A22. | ZN18C08007 | [5] | NUT | KOBM08x1.25mm |
| A23. | ZW16P08000 | [3] | WASHER | KOBID 08 x OD 17 x Th 1.6mm |
| A24. | ZM73C10020 | [9] | BOLT,M10x20mm - Course Thread | KOBM10x1.50x20mm (Incls. Washer) |
| A25. | YB13E01050P1 | [2] | GROMMET | KOB |
| A26. | ZM73C08020 | [13] | BOLT,M8x20mm - Course Thread | KOBM08x1.25x20mm (Incls. Washer) |
| A27. | EW02E01015D3 | [1] | CLIP | KOB |
| A28. | PX32W01059P1 | [1] | COLLAR | KOB |
| A29. | ZW26X08000 | [2] | LOCK WASHER | KOBLock Superseded by part number: 83990583 |
| A30. | ZM73C08025 | [1] | BOLT,M8x25mm - Course Thread | KOBM08x1.25x25mm (Incls. Washer) |
| A32. | YB13E01057P1 | [1] | PLATE | KOB |
| A33. | YB13E01062P1 | [1] | CABLE | KOB |
| A34. | LC13E01248P1 | [1] | BRACKET | KOB |
| A35. | ZM73C08016 | [2] | BOLT,M8x16mm - Course Thread | KOBM08x1.25x16mm (Incls. Washer) |
| A36. | ZM73C12020 | [2] | BOLT,M12x20mm - Course Thread | KOBSEMS |
| A37. | ZM73C08035 | [1] | BOLT,M8x35mm - Course Thread | KOBSEMS |
| A38. | ZY26X04020 | [1] | SPACER | KOB |
| A39. | EW02E01016D4 | [2] | CLIP | KOB |
| A40. | ZM73C06016 | [2] | BOLT,M6x16mm - Course Thread | KOBM06x1.0x16mm (Incls. Washer) |
| A41. | ZW16P06000 | [2] | WASHER | KOB |
| B1. | YB03Z00009P1 | [1] | SCHEMATIC, ELEC, (NOT IN SERVICE) | |
