| 1. |
84265086
|
[1] |
WIRE HARNESS
|
ZED
,, Serial Range: -C035 Superseded by part number: 47417234
|
| 1. |
47417234
|
[1] |
WIRE HARNESS
|
ZED
,, Start Serial: D036
|
| 2. |
84273809
|
[1] |
WIRE HARNESS
|
ZED
, Serial Range: -C098 Superseded by part number: 47635778
|
| 2. |
47635778
|
[1] |
WIRE HARNESS
|
ZED
, Start Serial: D099
|
| 3. |
87342073
|
[1] |
SENSOR
|
GI
B001 - Sensor Flywheel Brake
|
| 4. |
84391774
|
[1] |
SENSOR
|
ZED
B013 - Sensor Stuffer Trip
|
| 5. |
140045
|
[1] |
BELLEVILLE WASHER,M10 Bolt Size x 22mm OD x 1.6mm Thk
|
NH
|
| 6. |
86590413
|
[6] |
BASE,15.87mm W x 22.22mm OAL x 9.9mm Thk
|
ZED
|
| 7. |
445394
|
[1] |
RIVET,Pop, 3/16" x 1/2" OAL
|
ZED
Superseded by part number: 151-573
|
| 8. |
9706748
|
[2] |
CLAMP,15.9mm, Coat, 8.7mm Bolt Hole, P Type
|
NH
|
| 9. |
84191453
|
[1] |
SOCKET,12/24V, 20A
|
DUB
|
| 10. |
322358
|
[1] |
BELLEVILLE WASHER,M8 Bolt Size x 18mm OD x 1.4mm Thk
|
NH
|
| 11. |
86637976
|
[3] |
CLAMP,19mm, Coat, 8.7mm Bolt Hole, P Type
|
FAR
, Serial Range: -C098
|
| 12. |
322357
|
[8] |
BELLEVILLE WASHER,M6 Bolt Size x 14mm OD x 1.3mm Thk
|
NH
|
| 13. |
120100
|
[4] |
BOLT,M6 x 20mm, Cl 8.8
|
NH
|
| 14. |
9706755
|
[1] |
NUT,M6, Cl 8
|
NH
Superseded by part number: 86500688
|
| 15. |
858956
|
[5] |
CLAMP,11.1mm, Coat, 8.7mm Bolt Hole, P Type
|
NH
|
| 16. |
86050346
|
[1] |
CLAMP,9.5mm, Coat, 7.1mm Bolt Hole, P Type
|
WIN
|
| 17. |
86566990
|
[1] |
CABLE TIE,292mm OAL x 4.8mm W
|
ZED
|
| 18. |
86523197
|
[1] |
SENSOR
|
ZED
B016 - Sensor Density Pressure
|
| 19. |
700514
|
[3] |
CLAMP,3.8mm, Coat, M8 Bolt
|
NH
|
| 20. |
43127
|
[3] |
BOLT,Hex, M8 x 1.25 x 25mm, Cl 8.8
|
NH
|
| 21. |
378243
|
[3] |
WASHER,8.4mm ID x 21mm OD x 1.6mm Thk
|
NH
Superseded by part number: 63707, 63707, 86625263
|
| 22. |
412250
|
[3] |
NUT,M8 x 1.25, Cl 8
|
WIN
Superseded by part number: 86528579
|
| 23. |
9706690
|
[1] |
NUT,M8 x 1.25, Cl 8
|
NH
Superseded by part number: 43362
|
| 25. |
9824259
|
[2] |
WASHER,6.4mm ID x 12mm OD x 1.6mm Thk
|
NH
|
| 26. |
291186
|
[1] |
PROTECTION STRIP,9.9mm W
|
NH
L = 0.4 M Superseded by part number: 47560081, 47560080
|
| 27. |
401310
|
[1] |
PROFILE
|
ZED
L = 0.73 M
|
| 29. |
84058832
|
[1] |
CLIP
|
ZED
|
| 30. |
120101
|
[1] |
BOLT,Hex, M6 x 1 x 30mm, Cl 8.8
|
NH
Superseded by part number: 87317695
|
| 31. |
140160
|
[1] |
WASHER,8.20mm ID x 14.00mm OD x 0.80mm, 2.40mm
|
ZED
,, Start Serial: D036
|
| 32. |
401266
|
[1] |
STRIP-GASKET
|
ZED
, Start Serial: D072
|
| 33. |
412152
|
[1] |
NUT,M6 x 1, Cl 8.8
|
ZED
, Start Serial: D072
|
