纽荷兰零件查询(E235BSRNLC) - CRAWLER EXCAVATOR ASN YU05-02001 (01-077) - HARNESS ASSY, ENGINE New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
849 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YB16E00002F1 | [1] | HARNESS ASSY, ENGINE | |
| 1. | LQ16E01015P1 | [1] | HARNESS | KOB |
| 2. | YB16E01007P1 | [1] | BRACKET | KOB |
| 3. | EW02E01016D2 | [2] | CLIP | KOB |
| 4. | PY01P01043D3 | [1] | CABLE TIE,188mm L | KOBWire Ties -- 188mm Long |
| 5. | ZM73C08020 | [3] | BOLT,M8x20mm - Course Thread | KOBM08x1.25x20mm (Incls. Washer) |
| 7. | LQ16E01019P1 | [1] | BRACKET | KOB |
| 8. | YB16E01009P1 | [1] | BRACKET | KOB |
| 10. | ZM73C06020 | [2] | BOLT,M6x20mm - Course Thread | KOBSEMS |
| 12. | ZY26X04010 | [1] | SPACER | KOB |
