现代零件查询R28-7 SLEW MOTOREPC Hyundai
广数供应链运营团队, 15 02月, 2025，浏览：
392 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
XJDH-01957
|
[1] |
SLEW MOTOR
|
|
| 2. |
XJDH-01051
|
[2] |
PIN-KNOCK
|
|
| 3. |
XJDH-00072
|
[4] |
BOLT
|
|
| 4. |
XJDH-00280
|
[4] |
WASHER
|
|
| 5. |
XJDH-00452
|
[2] |
CONNECTOR-MALE
|
|
| 6. |
XJDH-00472
|
[1] |
ELBOW-MALE 90
|
|
| 7. |
XJDH-00467
|
[1] |
ELBOW-MALE 90
|
|
| 8. |
XJDH-00411
|
[1] |
TEE-MALE RUN
|
|
| 9. |
XJDH-03225
|
[1] |
SLOW MOTOR
|
|
| 901. |
XJDH-03283
|
[1] |
REDUCTION GEAR
|
|
| 902. |
XJDH-03284
|
[1] |
PISTON KIT
|
|
| 903. |
XJDH-03285
|
[1] |
RING SEAL
|
|
| 904. |
XJDH-03286
|
[1] |
O-RING
|
|
| 905. |
XJDH-03287
|
[4] |
BOLT-SOCKET HEAD
|
|
| 906. |
XJDH-03288
|
[1] |
RING
|
|
| 907. |
XJDH-03289
|
[1] |
HYDRAULIC MOTOR
|
|
| 908. |
XJDH-03290
|
[1] |
BODY KIT
|
|
| 909. |
XJDH-03291
|
[1] |
CYLINDER BARREL KIT
|
|
| 910. |
XJDH-03292
|
[1] |
SWASH PLATE KIT
|
|
| 911. |
XJDH-03293
|
[1] |
SEAL KIT
|
|
| 912. |
XJDH-03294
|
[2] |
FILTER
|
|
| 913. |
XJDH-03295
|
[1] |
BEARING-BALL
|
|
| 914. |
XJDH-03296
|
[1] |
BEARING-BALL
|
|
| K915. |
XJDH-03286
|
[1] |
O-RING
|
|
| 916. |
XJDH-03297
|
[1] |
RING-SNAP
|
|
| 917. |
XJDH-03298
|
[8] |
BOLT-SOCKET HEAD
|
|
| 918. |
XJDH-03299
|
[1] |
PIN-SPRING
|
|
| 919. |
XJDH-03300
|
[1] |
PIN
|
|
| K920. |
XJDH-03301
|
[1] |
O-RING
|
|
| K921. |
XJDH-03302
|
[1] |
O-RING
|
|
| K922. |
XJDH-00328
|
[2] |
O-RING
|
|
| 923. |
XJDH-03303
|
[2] |
RELIEF VALVE
|
|
| K924. |
XJDH-00331
|
[1] |
O-RING
|
|
| K925. |
XJDH-00334
|
[1] |
O-RING
|
|
| K926. |
XJDH-00335
|
[1] |
O-RING
|
|
| K927. |
XJDH-03304
|
[1] |
O-RING
|
|
| K928. |
XJDH-03305
|
[2] |
RING-BACK UP
|
|
| 929. |
XJDH-03306
|
[1] |
SEAL KIT
|
|
