现代零件查询R28-7 TRAVEL MOTOREPC Hyundai
广数供应链运营团队, 15 02月, 2025，浏览：
283 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
XJDH-01488
|
[1] |
TRAVEL MOTOR ASSY
|
|
| 101. |
XJDH-03271
|
[1] |
SEAL KIT
|
|
| 102. |
XJDH-03272
|
[1] |
SEAL KIT
|
|
| 103. |
XJDH-03273
|
[1] |
SEAL-OIL
|
|
| 104. |
XJDH-03307
|
[1] |
O-RING
|
|
| 105. |
XJDH-03308
|
[1] |
O-RING
|
|
| 106. |
XJDH-03309
|
[1] |
O-RING
|
|
| 107. |
XJDH-03310
|
[1] |
O-RING
|
|
| 108. |
XJDH-03311
|
[1] |
O-RING
|
|
| 109. |
XJDH-03312
|
[2] |
O-RING
|
|
| 110. |
XJDH-03313
|
[2] |
O-RING
|
|
| 111. |
XJDH-03314
|
[2] |
O-RING
|
|
| 112. |
XJDH-03315
|
[2] |
O-RING
|
|
| 113. |
XJDH-03316
|
[1] |
O-RING
|
|
| 114. |
XJDH-03317
|
[1] |
SEAL-OIL
|
|
| 115. |
XJDH-03318
|
[1] |
RING-BACK UP
|
|
| 116. |
XJDH-03319
|
[1] |
SEAL-PISTON
|
|
| 117. |
XJDH-03320
|
[1] |
SEAL-PISTON
|
|
| 2. |
XJDH-00071
|
[9] |
BOLT
|
|
| 3. |
XJDH-00278
|
[9] |
WASHER
|
|
| 4. |
XJDH-00452
|
[2] |
CONNECTOR-MALE
|
|
| 5. |
XJDH-00472
|
[1] |
ELBOW-MALE 90
|
|
| 6. |
XJDH-00467
|
[1] |
ELBOW-MALE 90
|
|
