现代零件查询R28-7 BUCKET CYLINDEREPC Hyundai
广数供应链运营团队, 15 02月, 2025，浏览：
168 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
XJDH-01962
|
[1] |
BUCKET CYLINDER
|
|
| 101. |
XJDH-02171
|
[1] |
TUBE ASSY-CYL
|
|
| 102. |
XJDH-02172
|
[1] |
PISTON ROD ASSY
|
|
| 103. |
XJDH-02173
|
[1] |
HEAD ASSY-CYL
|
|
| 104. |
XJDH-02174
|
[1] |
HEAD-CYL
|
|
| 105. |
XJDH-02175
|
[1] |
BUSHING
|
|
| 106. |
XJDH-02176
|
[1] |
U-RING
|
|
| 107. |
XJDH-02177
|
[1] |
RING-WIPER
|
|
| 108. |
XJDH-00350
|
[1] |
O-RING
|
|
| 109. |
XJDH-02178
|
[1] |
RING-BACK UP
|
|
| 110. |
XJDH-00351
|
[1] |
O-RING
|
|
| 111. |
XJDH-02179
|
[1] |
RING-BACK UP
|
|
| 112. |
XJDH-02180
|
[1] |
PISTON ASSY
|
|
| 113. |
XJDH-02181
|
[1] |
PISTON
|
|
| 114. |
XJDH-02182
|
[1] |
SEAL RING ASSY
|
|
| 115. |
XJDH-02183
|
[2] |
RING-SLIDE
|
|
| 116. |
XJDH-02156
|
[1] |
SCREW-SET
|
|
| 117. |
XJDH-02157
|
[1] |
BALL-STEEL
|
|
| 118. |
XJDH-02184
|
[1] |
PIPE ASSY
|
|
| 119. |
XJDH-02185
|
[1] |
PIPE ASSY
|
|
| 120. |
XJDH-02160
|
[2] |
PLUG ASSY
|
|
| 121. |
XJDH-02161
|
[2] |
PLUG
|
|
| 122. |
XJDH-00335
|
[4] |
O-RING
|
|
| 123. |
XJDH-02162
|
[2] |
BOLT-UPSET
|
|
| 124. |
XJDH-02163
|
[2] |
HOLDER-PIPE
|
|
| 125. |
XJDH-02170
|
[4] |
SEAL-DUST
|
|
| 126. |
XJDH-00373
|
[1] |
NIPPLE-GREASE
|
|
| 127. |
XJDH-00377
|
[1] |
NIPPLE-GREASE 90
|
|
| 128. |
XJDH-02186
|
[1] |
PACKING ASSY
|
|
| 129. |
XJDH-02203
|
[1] |
BUSHING
|
|
| 130. |
XJDH-02204
|
[1] |
BUSHING
|
|
| 2. |
XJDH-00452
|
[2] |
CONNECTOR-MALE
|
|
