现代零件查询R28-7 DOZER CYLINDEREPC Hyundai
广数供应链运营团队, 15 02月, 2025，浏览：
870 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
XJDH-01964
|
[1] |
DOZER CYLINDER
|
|
| 101. |
XJDH-02197
|
[1] |
TUBE ASSY-CYL
|
|
| 102. |
XJDH-02198
|
[1] |
PISTON ROD ASSY
|
|
| 103. |
XJDH-02140
|
[1] |
HEAD ASSY-CYL
|
|
| 104. |
XJDH-02141
|
[1] |
HEAD-CYL
|
|
| 105. |
XJDH-02142
|
[1] |
BUSHING
|
|
| 106. |
XJDH-02143
|
[1] |
U-RING
|
|
| 107. |
XJDH-02144
|
[1] |
RING-WIPER
|
|
| 108. |
XJDH-00351
|
[1] |
O-RING
|
|
| 109. |
XJDH-02145
|
[1] |
RING-BACK UP
|
|
| 110. |
XJDH-00352
|
[1] |
O-RING
|
|
| 111. |
XJDH-02152
|
[1] |
PISTON ASSY
|
|
| 112. |
XJDH-02153
|
[1] |
PISTON
|
|
| 113. |
XJDH-02154
|
[1] |
RING ASSY-SEAL
|
|
| 114. |
XJDH-02155
|
[2] |
RING-SLIDE
|
|
| 115. |
XJDH-02156
|
[1] |
SCREW-SET
|
|
| 116. |
XJDH-02157
|
[1] |
BALL-STEEL
|
|
| 117. |
XJDH-02170
|
[4] |
SEAL-DUST
|
|
| 118. |
XJDH-00373
|
[1] |
NIPPLE-GREASE
|
|
| 119. |
XJDH-00376
|
[1] |
NIPPLE-GREASE 45
|
|
| 120. |
XJDH-02196
|
[1] |
PACKING ASSY
|
|
| 121. |
XJDH-02207
|
[1] |
BUSHING
|
|
| 122. |
XJDH-02208
|
[1] |
BUSHING
|
|
| 2. |
XJDH-00467
|
[2] |
ELBOW-MALE 90
|
|
