凯斯零件查询(LB324S) - BALER (9/12-) (60.240.050) - PACKER CLUTCH - C150 Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
522 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
84261363
|
[1] |
SLIP CLUTCH
|
ZED
Incl 2 - 14
|
| 2. |
84261364
|
[1] |
SPROCKET
|
ZED
|
| 3. |
84800488
|
[1] |
CLUTCH DISC
|
ZED
|
| 4. |
84045306
|
[1] |
BUSHING,44.98mm ID x 50.02mm OD x 50mm L
|
ZED
|
| 5. |
84041818
|
[1] |
GEAR
|
ZED
|
| 6. |
84041833
|
[1] |
CIRCLIP
|
ZED
|
| 7. |
261798
|
[4] |
CLUTCH PLATE,101.6mm ID x 174.6mm OD x 7.11mm Thk
|
NH
|
| 8. |
84041824
|
[3] |
DISC,97mm ID x 230mm OD x 3.5mm Thk
|
ZED
|
| 9. |
84041827
|
[1] |
CLUTCH DISC
|
ZED
|
| 10. |
84349340
|
[9] |
TUBE
|
ZED
, Serial Range: -C094 Superseded by part number: 47604645
|
| 10. |
47604645
|
[9] |
TUBE
|
ZED
, Start Serial: D095
|
| 11. |
322270
|
[9] |
SPRING
|
ZED
|
| 12. |
9832748
|
[9] |
WASHER
|
ZED
Superseded by part number: 140042
|
| 13. |
331168
|
[9] |
BOLT,Hex, M10 x 1.5 x 140mm, Cl 8.8
|
NH
, Serial Range: -C094
|
| 13. |
PA7120741
|
[9] |
BOLT
|
PA
, Start Serial: D095 Superseded by part number: 11109031
|
| 14. |
9820493
|
[1] |
WASHER,20.5mm ID x 35mm OD x 2mm Thk
|
ZED
|
