现代零件查询R28-7 CONSOLE-RHEPC Hyundai
广数供应链运营团队, 15 02月, 2025，浏览：
124 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
XJDH-01598
|
[1] |
STAND-LEVER(RH)
|
|
| 2. |
XJDH-00035
|
[4] |
BOLT
|
|
| 3. |
XJDH-00276
|
[4] |
WASHER
|
|
| 4. |
XJDH-02435
|
[1] |
COVER(R)
|
|
| 5. |
XJDH-01600
|
[1] |
COVER
|
|
| 6. |
XJDH-01601
|
[1] |
COVER
|
|
| 7. |
XJDH-00229
|
[10] |
SCREW-TRUSTHEAD
|
|
| 8. |
XJDH-02831
|
[1] |
METER UNIT
|
|
| 9. |
XJDH-00233
|
[4] |
SCREW-PANHEAD
|
|
| 10. |
XJDH-00251
|
[4] |
WASHER
|
|
| 15. |
XJDH-02838
|
[1] |
LIGHTER-CIGARETTE
|
|
| 16. |
XJDH-02520
|
[1] |
SWITCH
|
|
| 17. |
XJDH-01809
|
[1] |
KEY SWITCH ASSY
|
|
| 1701. |
XJDH-02515
|
[1] |
SWITCH-KEY
|
|
| 1702. |
XJDH-00846
|
[1] |
COVER
|
|
| 1703. |
XJDH-02516
|
[1] |
HARNESS-STARTER
|
|
