纽荷兰零件查询(E235SRLC) - CRAWLER EXCAVATOR BTW YU04-00837 - YU04-01417 (03-005) - HYD LINES, ARM 2.94M New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
503 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 0. | YN01V00112F5 | [1] | BUCKET CYLINDER | KOBCYLINDER ASSY,BUCKET, SEE (C. P. M) |
| . . | YN12B00358F1 | [1] | CYLINDER INSTAL | |
| A1. | YN12B01707P1 | [1] | PIN | KOB |
| A2. | HS18C16140G2 | [1] | SCREW,M16 x 140mm, Cl 10.9 | KOBCAP |
| A3. | ZN18C16013 | [2] | NUT | KOB |
| A4. | YN12B01601D1 | [2] | SHIM,82mm ID x 140mm OD x 2mm Thk | KOB(2.0) |
| A5. | YN12B01122D1 | [1] | SHIM,82mm ID x 140mm OD x 0.5mm Thk | KOB(0.5) |
| A6. | YN12B01122D2 | [1] | SHIM,82mm ID x 140mm OD x 0.9mm Thk | KOB(0.9) |
| A7. | YN12B01122D3 | [1] | SHIM,82mm ID x 140mm OD x 1.6mm Thk | KOB(1.6) |
| . . | YN43H00106F1 | [1] | HYD LINES, CYLINDER (STD) | |
| . . | YN43H00106F2 | [1] | HYD LINES,CYLINDER (AUTO GREASER) | |
| B1. | YN43H01413P1 | [1] | TUBE | KOB |
| B2. | YN43H01097P1 | [1] | CLAMP | KOB |
| B3. | ZS18C10055 | [1] | SCREW,Hex, M10 x 55mm | KOBCAP |
| B4. | ZS28C10035 | [4] | SCREW,Hex Socket Head, M10 x 35mm | KOBSCREW |
| B5. | ZD12P02600 | [1] | O-RING | KOB |
| B6. | ZD12A01800 | [1] | O-RING,1.78mm Thk x 18.77mm ID, Cl 6 | KOB |
| B7. | ZG91U02000 | [1] | LUBE NIPPLE | KOBGREASE |
| B8. | ZG91S02000 | [1] | LUBE NIPPLE,1/8" NPT x 1/8" NPT | KOBGREASE, (FOR F1 ONLY) |
| B9. | ZW26X10000 | [1] | LOCK WASHER | KOBID 10 x OD 18 x Th 2.5mm |
| B10. | 2444Z2002 | [1] | HYD CONNECTOR | KOB(FOR F2 ONLY) |
| B11. | ZW16H10000 | [1] | WASHER | KOB |
| . . | YN43H00107F1 | [1] | HYD LINES, ARM | |
| C1. | ZX50H12125 | [1] | HOSE | KOB |
| C2. | YN43H01414D1 | [1] | HOSE | KOB |
| C3. | ZE13X12000 | [2] | CLAMP | KOBHALF |
| C5. | ZW26K10000 | [4] | LOCK WASHER | KOBLOCK |
