纽荷兰零件查询(E235SRLC) - CRAWLER EXCAVATOR BTW YU04-00837 - YU04-01417 (07-004[01]) - MOTOR ASSY (PROPELLING) New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
1007 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | NSS | [1] | NOT SERVICED SEPARATELY | CONFLANGE |
| 8. | 2436U1027S203 | [2] | SEAT/SLOT | KOBSPRING |
| 10. | 2436U1027S205 | [2] | SEAT/SLOT | KOBSPRING |
| 17. | YN23V00003F1 | [2] | PRESSURE RELIEF VALVE | KOBASSY, SEE FIG 07-025 |
| 21. | LQ15V00007S027 | [1] | SPRING | KOB |
| 22. | 2441U792S141 | [1] | PLUG | KOB |
| 24. | LQ15V00007S030 | [1] | GUIDE PIN | KOBSPRING |
| 25. | LQ15V00007S031 | [1] | PLUG | KOB |
| 36. | LQ15V00007S042 | [1] | SHAFT | KOB |
| 41. | YN15V00005S114 | [1] | SNAP RING | KOBRETAINING |
| 42. | YN15V00005S115 | [1] | SPRING SEAT | KOB |
| 43. | YN15V00005S116 | [1] | SPRING | KOBSPRING |
| 44. | YN15V00005S117 | [1] | RING | KOBCOLLAR |
| 45. | 2441U792S119 | [3] | PIN | KOB |
| 47. | 2441U792S110 | [2] | BALL | KOB |
| 49. | LQ15V00007S055 | [1] | BALL BEARING | KOB |
| 50. | LQ15V00007S056 | [1] | BALL BEARING | KOB |
| 52. | ZS23C14035 | [10] | SCREW,Hex Socket Head, M14 x 35mm | KOBCAP |
| 54. | LQ15V00007S060 | [3] | PLATE | KOBDISK |
| 55. | 2441U983S126 | [2] | PLATE | KOBFRICTION |
| 57. | 2441U984S42 | [1] | O-RING | KOB |
| 58. | 2441U983S130 | [1] | O-RING | KOB |
| 59. | 2441U792S130 | [8] | SPRING | KOB |
| 60. | YN15V00005S128 | [4] | PIN | KOBPIN |
| 61. | YN15V00005S139 | [2] | SPRING | KOB |
| 71. | LQ15V00007S077 | [2] | BEARING | KOBANGULAR |
| 75. | LQ15V00007S081 | [8] | FRICTION WASHER | KOB |
| 76. | LQ15V00007S082 | [8] | SCREW | KOBCAP |
| 77. | LQ15V00007S083 | [4] | PLATE | KOBTHRUST |
| 78. | LQ15V00007S084 | [4] | RACE | KOBINNER |
| 80. | LQ15V00007S086 | [4] | DRIVEN GEAR | KOB |
| 82. | LQ15V00007S088 | [4] | SCREW | KOBCAP |
| 84. | LQ15V00007S090 | [1] | RING | KOBRETAINING |
| 86. | LQ15V00007S092 | [3] | PLATE | KOBTHRUST |
| 90. | LQ15V00007S096 | [3] | PLATE | KOBTHRUST |
| 92. | LQ15V00007S098 | [3] | SCREW | KOB |
| 95. | LQ15V00007S101 | [1] | COVER | KOB |
| 96. | ZS23C10016 | [16] | SCREW,Hex Socket Head, M10 x 16mm | KOBCAP Superseded by part number: ZS28C10016 |
| 97. | LQ15V00007S103 | [3] | PLUG | KOB |
| 99. | LQ15V00007S105 | [4] | PIN | KOB |
| . . | LQ15V00019R200 | [1] | REPAIR KIT | KOBCONSISTS OF REF. 70(2), 98(3) Superseded by part number: LQ15V00031R200 |
| . . | LQ15V00007R700 | [1] | REPAIR KIT | KOBCONSISTS OF REF. 73(1) (0.05, 0.1, 0.3, 0.5, 1.0) |
| . . | LQ15V00007R800 | [1] | REPAIR KIT | KOBCONSISTS OF REF. 94(1) (2.3, 2.8, 3.0, 3.2, 3.6) |
