| 101. | NSS | [1] | NOT SERVICED SEPARATELY | CONCASE |
| 153. | YN30V00050S153 | [1] | PLUG | KOB |
| 154. | YN30V00001S154 | [3] | PLUG | KOB |
| 155. | YW30V00001S155 | [2] | PLUG | KOB |
| 156. | YN30V00001S156 | [2] | PLUG | KOB Superseded by part number: YW30V00001S156 |
| 158. | YN30V00001S158 | [1] | PLUG | KOB |
| 161. | ZD12P03800 | [7] | O-RING | KOB |
| 162. | ZD12G03000 | [12] | O-RING,29.40mm ID x 35.60mm OD x 3.10mm | KOB |
| 163. | ZD12P01500 | [4] | O-RING | KOB |
| 164. | ZD12P02400 | [14] | O-RING | KOB |
| 165. | ZD12P02900 | [1] | O-RING | KOB |
| 166. | ZD12P01400 | [2] | O-RING | KOBID 13.80 ± 0.19 x OD 18mm |
| 168. | ZD12P00800 | [1] | O-RING,1.9mm Thk x 7.8mm ID, 90 Duro | KOB |
| 169. | ZD12P01800 | [2] | O-RING | KOB |
| 201. | 2436U1165S201 | [3] | COVER | KOBSPRING |
| 202. | YN30V00079S202 | [1] | COVER | KOBSPRING |
| 203. | 2436U1265S201 | [3] | COVER | KOBSPRING Superseded by part number: 2436U2631S201 |
| 204. | YN30V00021S207 | [4] | COVER | KOBSPRING |
| 205. | YN30V00001S205 | [8] | COVER | KOBSPOOL |
| 207. | YN30V00071S207 | [1] | COVER | KOBSPRING |
| 211. | YX30V00009F1 | [2] | LOCK VALVE | KOBASSY, SEE FIG 07-046 |
| 212. | YN30V00079S212 | [2] | PLATE | KOB |
| 261. | YN30V00079S261 | [5] | O-RING | KOB |
| 262. | YY30V00031S262 | [7] | O-RING | KOB Superseded by part number: 2436U1457S162 |
| 264. | ZD12G04000 | [8] | O-RING,39.40mm ID x 45.60mm OD x 3.10mm | KOB |
| 273. | ZS23C08025 | [40] | SCREW,Hex Socket Head, M8 x 25mm | KOBCAP |
| 274. | ZS23C12025 | [8] | CAPSCREW,Hex Socket Head, M12 x 52mm | KOBSCREW CAP |
| 301. | YN30V00079S301 | [1] | REPAIR KIT | KOBSPOOL ASSY Superseded by part number: YN30V00071R100 |
| 302. | YN30V00071S302 | [1] | SPOOL | KOBASSY Superseded by part number: YN30V00071R110 |
| 304. | YN30V00079S304 | [1] | REPAIR KIT | KOBSPOOL Superseded by part number: YN30V00071R120 |
| 305. | YN30V00079S305 | [1] | SPOOL | KOB Superseded by part number: YN30V00071R160 |
| 307. | YN30V00079S307 | [1] | SPOOL | KOB |
| 309. | YN30V00079S309 | [1] | REPAIR KIT | KOBSPOOL Superseded by part number: YN30V00071R190 |
| 310. | YN30V00079S310 | [1] | SPOOL | KOB Superseded by part number: YN30V00071R200 |
| 321. | YN30V00079S321 | [4] | SPRING | KOB |
| 322. | YN30V00079S322 | [4] | SPRING | KOB |
| 323. | YN30V00079S323 | [1] | SPRING | KOB |
| 324. | YN30V00079S324 | [1] | SPRING | KOB |
| 325. | YN30V00079S325 | [4] | SPRING | KOB |
| 326. | YN30V00079S326 | [4] | SPRING | KOB |
| 327. | YN30V00001S325 | [3] | SPRING | KOB |
| 328. | YN30V00001S327 | [2] | SPRING | KOB |
| 329. | YN30V00001S328 | [1] | SPRING | KOB |
| 331. | 2436U1443S332 | [10] | SPRING SEAT | KOB |
| 332. | 2436U1265S332 | [14] | SPRING SEAT | KOB |
| 333. | 2436U1165S336 | [5] | BOLT | KOBSPACER |
| 334. | 2436U1265S336 | [7] | BOLT | KOBSPACER |
| 336. | 2436U1165S335 | [4] | STOP | KOB |
| 337. | 2436U1265S335 | [4] | STOP | KOB |
| 338. | YN30V00001S338 | [2] | STOP | KOB |
| 339. | YN30V00001S339 | [1] | STOP | KOB |
| 340. | YX30V00012S333 | [1] | STOP | KOB |
| 511. | 2436U1165S511 | [8] | POPPET | KOB |
| 512. | 2436U1265S511 | [5] | POPPET | KOB |
| 514. | YN30V00001S514 | [2] | POPPET | KOB |
| 521. | 2436U1165S521 | [7] | SPRING | KOB |
| 522. | 2436U1265S521 | [5] | SPRING | KOB |
| 523. | YN30V00089S523 | [1] | SPRING | KOB |
| 524. | YN30V00001S524 | [2] | SPRING | KOB |
| 551. | LQ30V00002S551 | [8] | PLUG | KOB Superseded by part number: YN30V00001S551 |
| 552. | YN30V00001S552 | [5] | PLUG | KOB Superseded by part number: YN30V00021S552 |
| 556. | YN30V00001S556 | [3] | PLUG | KOB |
| 562. | ZD12P02000 | [5] | O-RING,2.4mm Thk x 19.8mm ID, 90 Duro | KOB |
| 601. | YN22V00001F4 | [1] | PRESSURE RELIEF VALVE | KOBASSY, MAIN, SEE FIG 07-022 Superseded by part number: YN22V00001F8 |
| 602. | YN22V00002F1 | [2] | VALVE | KOBASSY, PORT RELIEF SEE FIG 07-023 AND 07-024 |
| 603. | YN22V00002F9 | [3] | VALVE | KOBVALVE ASSY, PORT RELIEF SEE FIG 07-023 AND 07-024 |
| 604. | YN22V00029F1 | [1] | VALVE | KOBASSY, PORT RELIEF |
| 973. | ZS23C14140 | [6] | SCREW,Hex Socket Head, M14 x 140mm | KOBCAP |
| 974. | ZS23C14100 | [2] | CAPSCREW,Hex Socket Head, M14 x 100mm | KOBSCREW CAP |
